ASSA Profile Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Profile Cylinders
British Oval Profile Cylinders
Model No. Description TL A B C Comp Sub SNS
Twin 6000 Classic
6531 61mm Large Single Cyl. 128.00 119.00 113.00
6531 71mm Large Single Cyl. 128.00 119.00 113.00
6531 81mm Large Single Cyl. 128.00 119.00 113.00
6534 61mm Small Single Cyl. 112.50 104.50 98.50
6534 71mm Small Single Cyl. 112.50 104.50 98.50
6534 81mm Small Single Cyl. 112.50 104.50 98.50
6532 61mm Double Cylinder 142.00 133.00 127.00
6532 71mm Double Cylinder 142.00 133.00 127.00
6532 81mm Double Cylinder 142.00 133.00 127.00
6533 40.5mm Single Cylinder 112.50 104.50 95.50
6533 45.5mm Single Cylinder 112.50 104.50 95.50
6533 50.5mm Single Cylinder 112.50 104.50 95.50
600 Series Classic
631 61mm Large Single Cyl. 122.00 113.00 —
631 71mm Large Single Cyl. 122.00 113.00 —
631 81mm Large Single Cyl. 122.00 113.00 —
634 61mm Small Single Cyl. 107.00 99.00 —
634 71mm Small Single Cyl. 107.00 99.00 —
634 81mm Small Single Cyl. 107.00 99.00 —
632 61mm Double Cylinder 135.00 126.00 —
632
71mm Double Cylinder 135.00 126.00 —
632
81mm Double Cylinder
135.00 126.00 —
633 40.5mm Single Cylinder 107.00 99.00 —
633
45.5mm Single Cylinder
107.00
99.00
—
633 50.5mm Single Cylinder 107.00 99.00 —
3.481 1.209 1.209 1.063
3.875 1.406 1.406 1.063
4.269 1.603 1.603 1.063
3.481 1.209 1.209 1.063
3.875 1.406 1.406 1.063
4.269 1.603 1.603 1.063
2.418 1.209 1.209 N/A
2.812 1.406 1.406 N/A
3.206 1.603 1.603 N/A
1.595 1.209 0.398 N/A
1.794 1.406 0.398 N/A
1.990 1.603 0.398 N/A
3.481 1.209 1.209 1.063
3.875 1.406 1.406 1.063
4.269
1.603
1.603 1.063
3.481 1.209 1.209 1.063
3.875
1.406 1.406 1.063
4.269
1.603
1.603
1.063
2.418 1.209 1.209 N/A
2.812
1.406
1.406
N/A
3.206 1.603 1.603 N/A
1.595 1.209 0.398 N/A
1.794 1.406 0.398 N/A
1.990 1.603 0.398 N/A
TL
ABC
Profile Cylinder Key:
TL
– Total Length
A – Exterior Length
B – Interior Length
C – Knob Length
