ASSA Profile Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Profile Cylinders
Din Euro Profile Cylinders
Model No. Description TL A B C Comp Sub SNS
Twin V-10
V6521 61mm Large Single Cyl. 98.50 89.00 84.00
V6521 71mm Large Single Cyl. 98.50 89.00 84.00
V6521 81mm Large Single Cyl. 98.50 89.00 84.00
V6524 61mm Small Single Cyl. 97.50 88.00 83.00
V6524 71mm Small Single CyL. 97.50 88.00 83.00
V6524 81mm Small Single Cyl. 97.50 88.00 83.00
V6522 61mm Double Cylinder 107.00 98.00 92.50
V6522 71mm Double Cylinder 107.00 98.00 92.50
V6522 81mm Double Cylinder 107.00 98.00 92.50
V6523 40.5mm Single Cylinder 68.00 59.00 54.00
V6523 45.5mm Single Cylinder 68.00 59.00 54.00
V6523 50.5mm Single Cylinder 68.00 59.00 54.00
Twin Exclusive
E6521 61mm Large Single Cyl. 98.50 89.00 84.00
E6521 71mm Large Single Cyl. 98.50 89.00 84.00
E6521
81mm Lar
ge Single Cyl.
98.50
89.00
84.00
E6524 61mm Small Single Cyl. 97.50 88.00 83.00
E6524
71mm Small Single CyL.
97.50
88.00
83.00
E6524 81mm Small Single Cyl. 97.50 88.00 83.00
E6522 61mm Double Cylinder 107.00 98.00 92.50
E6522 71mm Double Cylinder 107.00 98.00 92.50
E6522 81mm Double Cylinder 107.00 98.00 92.50
E6523 40.5mm Single Cylinder 68.00 59.00 54.00
E6523 45.5mm Single Cylinder 68.00 59.00 54.00
E6523 50.5mm Single Cylinder 68.00 59.00 54.00
3.470 1.210 1.210 1.050
3.864 1.407 1.407 1.050
4.258 1.604 1.604 1.050
3.480 1.210 1.210 1.065
3.864 1.407 1.407 1.065
4.258 1.604 1.604 1.065
4.420 1.210 1.210 N/A
2.814 1.407 1.407 N/A
3.208 1.604 1.604 N/A
1.571 1.203 0.368 N/A
1.768 1.400 0.368 N/A
1.965 1.597 0.368 N/A
3.470 1.210 1.210 1.050
3.864
1.407
1.407 1.050
4.258 1.604 1.604 1.050
3.480
1.210
1.210
1.065
3.864 1.407 1.407 1.065
4.258 1.604 1.604 1.065
4.420 1.210 1.210 N/A
2.814 1.407 1.407 N/A
3.208 1.604 1.604 N/A
1.571
1.203
0.368 N/A
1.768
1.400
0.368
N/A
1.965 1.597 0.368 N/A
TL
ABC
Profile Cylinder Key:
TL – T
otal Length
A – Exterior Length
B – Interior Length
C – Knob Length
