128
ASSA Profile Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Profile Cylinders
Din Euro Profile Cylinders
Model No. Description TL A B C Comp Sub SNS
Twin 6000 Classic
6521 61mm Large Single Cyl. 106.00 95.00 89.00
6521 71mm Large Single Cyl. 106.00 95.00 89.00
6521 81mm Large Single Cyl. 106.00 95.00 89.00
6524 61mm Small Single Cyl. 105.00 94.00 87.00
6524 71mm Small Single CyL. 105.00 94.00 87.00
6524 81mm Small Single Cyl. 105.00 94.00 87.00
6522 61mm Double Cylinder 116.00 105.00 99.00
6522 71mm Double Cylinder 116.00 105.00 99.00
6522 81mm Double Cylinder 116.00 105.00 99.00
6523 40.5mm Single Cylinder 74.00 62.00 56.00
6523 45.5mm Single Cylinder 74.00 62.00 56.00
6523 50.5mm Single Cylinder 74.00 62.00 56.00
600 Series Classic
621 61mm Large Single Cyl. 106.00 95.00 —
621 71mm Large Single Cyl. 106.00 95.00 —
621
81mm Lar
ge Single Cyl.
106.00
95.00
—
624 61mm Small Single Cyl. 105.00 94.00 —
624
71mm Small Single CyL.
105.00
94.00
—
624 81mm Small Single Cyl. 105.00 94.00 —
622 61mm Double Cylinder 116.00 105.00 —
622 71mm Double Cylinder 116.00 105.00 —
622 81mm Double Cylinder 116.00 105.00 —
623 40.5mm Single Cylinder 74.00 62.00 —
623 45.5mm Single Cylinder 74.00 62.00 —
623 50.5mm Single Cylinder 74.00 62.00 —
3.470 1.210 1.210 1.050
3.864 1.407 1.407 1.050
4.258 1.604 1.604 1.050
3.480 1.210 1.210 1.065
3.864 1.407 1.407 1.065
4.258 1.604 1.604 1.065
4.420 1.210 1.210 N/A
2.814 1.407 1.407 N/A
3.208 1.604 1.604 N/A
1.571 1.203 0.368 N/A
1.768 1.400 0.368 N/A
1.965 1.597 0.368 N/A
3.470 1.210 1.210 1.050
3.864
1.407
1.407 1.050
4.258 1.604 1.604 1.050
3.480
1.210
1.210
1.065
3.864 1.407 1.407 1.065
4.258 1.604 1.604 1.065
4.420 1.210 1.210 N/A
2.814 1.407 1.407 N/A
3.208 1.604 1.604 N/A
1.571
1.203
0.368 N/A
1.768
1.400
0.368
N/A
1.965 1.597 0.368 N/A
TL
ABC
Profile Cylinder Key:
TL – T
otal Length
A – Exterior Length
B – Interior Length
C – Knob Length
