Mortise Cylinders
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
1-1/8" Mortise Cylinder
Model/Cam# Description HD HT BL BD R-A R-B Comp Sub SNS
Twin Pro
† 6151-1 with Adams Rite Cam 82.00 72.50 65.50
† 6151-2
with Sargent Cam 82.00 72.50 65.50
† 6151-3 with Cor. Clover Leaf Cam 82.00 72.50 65.50
† 6151-4
with Cor. Beaver Tail Cam 82.00 72.50 65.50
† 6151-5 with Yale Standard Cam 82.00 72.50 65.50
† 6151-6 with Schlage “L” Cam 82.00 72.50 65.50
† 6151-7 with Segal Type Cam 82.00 72.50 65.50
† 6151-8 with Corbin Jumbo Cam 82.00 72.50 65.50
† 6151-9 with Best 30H Cam 82.00 72.50 65.50
† 6151-10 with Norment/AirTeq Cam 82.00 72.50 65.50
† 6151-11 with Mogul Cam 82.00 72.50 65.50
† 6151-12
w/ Cor. Jumbo Clover Leaf 82.00 72.50 65.50
† 6151-13 with Sargent Short Cam 82.00 72.50 65.50
† 6151-15 with Yale Rep. Cam 82.00 72.50 65.50
Twin Maximum
† 8851-1 with Adams Rite Cam 82.00 72.50 65.50
† 8851-2 with Sargent Cam 82.00 72.50 65.50
† 8851-3 with Cor. Clover Leaf Cam 82.00 72.50 65.50
† 8851-4 with Cor. Beaver Tail Cam 82.00 72.50 65.50
† 8851-5 with Yale Standard Cam 82.00 72.50 65.50
† 8851-6 with Schlage “L” Cam 82.00 72.50 65.50
† 8851-7 with Segal Type Cam 82.00 72.50 65.50
† 8851-8 with Corbin Jumbo Cam 82.00 72.50 65.50
† 8851-9 with Best 30H Cam 82.00 72.50 65.50
† 8851-10 with Norment/AirTeq Cam 82.00 72.50 65.50
† 8851-11 with Mogul Cam 82.00 72.50 65.50
† 8851-12 w/ Cor. Jumbo Clover Leaf 82.00 72.50 65.50
† 8851-13 with Sargent Short Cam 82.00 72.50 65.50
† 8851-15 with Yale Rep. Cam 82.00 72.50 65.50
Twin Maximum Medium Security
† 2851-1 with Adams Rite Cam 65.50 58.00 51.00
† 2851-2 with Sargent Cam 65.50 58.00 51.00
† 2851-3 with Cor. Clover Leaf Cam 65.50 58.00 51.00
† 2851-4 with Cor. Beaver Tail Cam 65.50 58.00 51.00
† 2851-5
with Y
ale Standard Cam 65.50 58.00 51.00
† 2851-6 with Schlage “L” Cam 65.50 58.00 51.00
† 2851-7 with Segal Type Cam 65.50 58.00 51.00
† 2851-8
with Corbin Jumbo Cam 65.50 58.00 51.00
† 2851-9 with Best 30H Cam 65.50 58.00 51.00
† 2851-10 with Norment/AirTeq Cam 65.50 58.00 51.00
† 2851-11 with Mogul Cam 65.50 58.00 51.00
† 2851-12 w/ Cor. Jumbo Clover Leaf 65.50 58.00 51.00
† 2851-13 with Sargent Short Cam 65.50 58.00 51.00
† 2851-15
with Y
ale Rep. Cam
65.50
58.00 51.00
T
win Low & T
win 600 Series Classic
Low 600 Description HD HT BL BD R-A R-B COMP SUB —
L651-1 651-1 with Adams Rite Cam 74.00 68.00 —
L651-2 651-2 with Sargent Cam 74.00 68.00 —
L651-3 651-3 with Cor. Clover Leaf Cam 74.00 68.00 —
L651-4 651-4 with Cor. Beaver Tail Cam 74.00 68.00 —
L651-5
651-5
with Y
ale Standar
d Cam
74.00
68.00 —
L651-6 651-6 with Schlage “L” Cam 74.00 68.00 —
L651-7 651-7 with Segal Type Cam 74.00 68.00 —
L651-8
651-8
with Corbin Jumbo Cam 74.00 68.00 —
L651-9 651-9 with Best 30H Cam 74.00 68.00 —
L651-10 651-10 with Norment/AirTeq Cam 74.00 68.00 —
L651-11 651-11 with Mogul Cam 74.00 68.00 —
L651-12
651-12
w/ Cor
. Jumbo Clover Leaf
74.00
68.00
—
L651-13 651-13 with Sargent Short Cam 74.00 68.00 —
L651-15
651-15
with Y
ale Rep. Cam
74.00
68.00 —
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 8851-1 x CLIQ x 626 x Sidebar x Comp
† Available in special function cylinders, see page 4, add $29.00.
1.366 0.138 1.125 1.157 0.118 0.555
1.366 0.138 1.125 1.157 N/A 0.709
1.366 0.138 1.125 1.157 0.114 0.602
1.366 0.138 1.125 1.157 N/A 0.732
1.366 0.138 1.125 1.157 N/A 0.709
1.366 0.138 1.125 1.157 0.124 0.516
1.366 0.138 1.125 1.157 N/A 0.779
1.366 0.138 1.125 1.157 N/A 0.914
1.366 0.138 1.125 1.157 0.114 0.602
1.366 0.138 1.125 1.157 N/A 0.787
1.366 0.138 1.125 1.157 N/A 1.165
1.366 0.138 1.125 1.157 0.114 0.828
1.366 0.138 1.125 1.157 N/A 0.515
1.366 0.138 1.125 1.157 0.742 0.308
1.366 0.138 1.125 1.157 0.118 0.555
1.366 0.138 1.125 1.157 N/A 0.709
1.366 0.138 1.125 1.157 0.114 0.602
1.366 0.138 1.125 1.157 N/A 0.732
1.366 0.138 1.125 1.157 N/A 0.709
1.366 0.138 1.125 1.157 0.124 0.516
1.366 0.138 1.125 1.157 N/A 0.779
1.366 0.138 1.125 1.157 N/A 0.914
1.366 0.138 1.125 1.157 0.114 0.602
1.366 0.138 1.125 1.157 N/A 0.787
1.366 0.138 1.125 1.157 N/A 1.165
1.366 0.138 1.125 1.157 0.114 0.828
1.366 0.138 1.125 1.157 N/A 0.515
1.366 0.138 1.125 1.157 0.742 0.308
1.366 0.138 1.125 1.157 0.118 0.555
1.366 0.138 1.125 1.157 N/A 0.709
1.366 0.138 1.125 1.157 0.114 0.602
1.366 0.138 1.125 1.157 N/A 0.732
1.366 0.138 1.125 1.157 N/A 0.709
1.366 0.138 1.125 1.157 0.124 0.516
1.366 0.138 1.125 1.157 N/A 0.779
1.366
0.138
1.125
1.157
N/A
0.914
1.366 0.138 1.125 1.157 0.114 0.602
1.366 0.138 1.125 1.157 N/A 0.787
1.366
0.138 1.125 1.157 N/A 1.165
1.366
0.138 1.125 1.157 0.114 0.828
1.366 0.138 1.125 1.157 N/A 0.515
1.366 0.138 1.125 1.157 0.742 0.308
1.366 0.138 1.125 1.157 0.118 0.555
1.366
0.138
1.125 1.157 N/A 0.709
1.366
0.138 1.125 1.157 0.114 0.602
1.366 0.138 1.125 1.157 N/A 0.732
1.366 0.138 1.125 1.157 N/A 0.709
1.366 0.138 1.125 1.157 0.124 0.516
1.366 0.138 1.125 1.157 N/A 0.779
1.366 0.138 1.125 1.157 N/A 0.914
1.366
0.138
1.125
1.157
0.114 0.602
1.366 0.138 1.125 1.157 N/A 0.787
1.366
0.138
1.125 1.157 N/A 1.165
1.366 0.138 1.125 1.157 0.114 0.828
1.366 0.138 1.125 1.157 N/A 0.515
1.366 0.138 1.125 1.157 0.742 0.308
