22
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise Cylinders
BL
HT
BD
HD
Available Cams
#11 #12 #13 #15
#1 #2 #3 #4 #5
#6
#7 #8 #9 #10
Mortise Cylinder Key:
HD
– Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
BD – Body Diameter
Cam Key:
R-A
– Head Radius • R-B – Overall Radius
1-1/4" Mortise Cylinder
Model/Cam# Description HD HT BL BD R-A R-B Comp Sub SNS
Twin V-10
† V6552-1 with Adams Rite Cam 83.00 73.50 66.50
† V6552-2 with Sargent Cam 83.00 73.50 66.50
† V6552-3 with Cor. Clover Leaf Cam 83.00 73.50 66.50
† V6552-4 with Cor. Beaver Tail Cam 83.00 73.50 66.50
† V6552-5 with Yale Standard Cam 83.00 73.50 66.50
† V6552-6 with Schlage “L” Cam 83.00 73.50 66.50
† V6552-7 with Segal Type Cam 83.00 73.50 66.50
† V6552-8 with Corbin Jumbo Cam 83.00 73.50 66.50
† V6552-9 with Best 30H Cam 83.00 73.50 66.50
† V6552-10 with Norment/AirTeq Cam 83.00 73.50 66.50
† V6552-11 with Mogul Cam 83.00 73.50 66.50
† V6552-12 with Cor. Jumbo Clover Leaf 83.00 73.50 66.50
† V6552-13 with Sargent Short Cam 83.00 73.50 66.50
† V6552-15 with Yale Rep. Cam 83.00 73.50 66.50
Twin Exclusive
† E6552-1 with Adams Rite Cam 83.00 73.50 66.50
† E6552-2 with Sargent Cam 83.00 73.50 66.50
† E6552-3 with Cor. Clover Leaf Cam 83.00 73.50 66.50
† E6552-4
with Cor. Beaver Tail Cam 83.00 73.50 66.50
† E6552-5 with Yale Standard Cam 83.00 73.50 66.50
† E6552-6 with Schlage “L” Cam 83.00 73.50 66.50
† E6552-7 with Segal Type Cam 83.00 73.50 66.50
† E6552-8 with Corbin Jumbo Cam 83.00 73.50 66.50
† E6552-9 with Best 30H Cam 83.00 73.50 66.50
†
E6552-10
with Norment/AirTeq Cam 83.00 73.50 66.50
† E6552-11 with Mogul Cam 83.00 73.50 66.50
† E6552-12 with Cor. Jumbo Clover Leaf 83.00 73.50 66.50
† E6552-13 with Sargent Short Cam 83.00 73.50 66.50
†
E6552-15
with Y
ale Rep. Cam
83.00
73.50
66.50
Twin 6000 Classic
†
6552-1
with Adams Rite Cam
95.00 86.00 77.00
†
6552-2 with Sargent Cam 95.00 86.00 77.00
† 6552-3 with Cor. Clover Leaf Cam 95.00 86.00 77.00
† 6552-4 with Cor. Beaver Tail Cam 95.00 86.00 77.00
† 6552-5 with Yale Standard Cam 95.00 86.00 77.00
† 6552-6 with Schlage “L” Cam 95.00 86.00 77.00
† 6552-7 with Segal Type Cam 95.00 86.00 77.00
†
6552-8
with Corbin Jumbo Cam
95.00
86.00 77.00
† 6552-9 with Best 30H Cam 95.00 86.00 77.00
†
6552-10
with Norment/AirTeq Cam 95.00 86.00 77.00
† 6552-11 with Mogul Cam 95.00 86.00 77.00
† 6552-12 with Cor. Jumbo Clover Leaf 95.00 86.00 77.00
† 6552-13 with Sargent Short Cam 95.00 86.00 77.00
†
6552-15
with Y
ale Rep. Cam
95.00
86.00
77.00
† Available in special function cylinders, see page 4, add $29.00.
1.366 0.138 1.25 1.157 0.118 0.555
1.366 0.138 1.25 1.157 N/A 0.709
1.366 0.138 1.25 1.157 0.114 0.602
1.366 0.138 1.25 1.157 N/A 0.732
1.366 0.138 1.25 1.157 N/A 0.709
1.366 0.138 1.25 1.157 0.124 0.516
1.366 0.138 1.25 1.157 N/A 0.779
1.366 0.138 1.25 1.157 N/A 0.914
1.366 0.138 1.25 1.157 0.114 0.602
1.366 0.138 1.25 1.157 N/A 0.787
1.366 0.138 1.25 1.157 N/A 1.165
1.366 0.138 1.25 1.157 0.114 0.828
1.366 0.138 1.25 1.157 N/A 0.515
1.366 0.138 1.25 1.157 0.742 0.308
1.366 0.138 1.25 1.157 0.118 0.555
1.366 0.138 1.25 1.157 N/A 0.709
1.366 0.138 1.25 1.157 0.114 0.602
1.366 0.138 1.25 1.157 N/A 0.732
1.366 0.138 1.25 1.157 N/A 0.709
1.366
0.138
1.25
1.157 0.124 0.516
1.366 0.138 1.25 1.157 N/A 0.779
1.366 0.138 1.25 1.157 N/A 0.914
1.366 0.138 1.25 1.157 0.114 0.602
1.366 0.138 1.25 1.157 N/A 0.787
1.366
0.138
1.25
1.157
N/A 1.165
1.366 0.138 1.25 1.157 0.114 0.828
1.366
0.138 1.25 1.157 N/A 0.515
1.366 0.138 1.25 1.157 0.742 0.308
1.366 0.138 1.25 1.157 0.118 0.555
1.366
0.138
1.25
1.157 N/A 0.709
1.366 0.138 1.25 1.157 0.114 0.602
1.366 0.138 1.25 1.157 N/A 0.732
1.366 0.138 1.25 1.157 N/A 0.709
1.366
0.138
1.25
1.157
0.124
0.516
1.366 0.138 1.25 1.157 N/A 0.779
1.366 0.138 1.25 1.157 N/A 0.914
1.366
0.138
1.25
1.157
0.114
0.602
1.366 0.138 1.25 1.157 N/A 0.787
1.366
0.138
1.25 1.157 N/A 1.165
1.366
0.138 1.25 1.157 0.114 0.828
1.366 0.138 1.25 1.157 N/A 0.515
1.366 0.138 1.25 1.157 0.742 0.308
