52
ASSA Rim Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Rim Cylinders
BL
HT
R
HD
1-1/8" Rim Cylinder
Available Tailpieces
Model/TP# Description HD HT BL R Comp Sub SNS
T
win V-10
† V6551-H with Horizontal Tailpiece 85.00 77.50 70.50
† V6551-V with Vertical Tailpiece 85.00 77.50 70.50
† V6551-L with Lazy-motion Tailpiece 85.00 77.50 70.50
Twin Exclusive
† E6551-H with Horizontal Tailpiece 85.00 77.50 70.50
† E6551-V with Vertical Tailpiece 85.00 77.50 70.50
† E6551-L with Lazy-motion Tailpiece 85.00 77.50 70.50
Twin 6000 Classic
† 6551-H with Horizontal Tailpiece 100.00 91.00 82.00
† 6551-V with Vertical Tailpiece 100.00 91.00 82.00
† 6551-L with Lazy-motion Tailpiece 100.00 91.00 82.00
Twin Pro
† 6151-H with Horizontal Tailpiece 85.00 77.50 70.50
† 6151-V with Vertical Tailpiece 85.00 77.50 70.50
† 6151-L with Lazy-motion Tailpiece 85.00 77.50 70.50
Twin Maximum
† 8851-H with Horizontal Tailpiece 85.00 77.50 70.50
† 8851-V with Vertical Tailpiece 85.00 77.50 70.50
† 8851-L with Lazy-motion Tailpiece 85.00 77.50 70.50
Twin Maximum Medium Security
† 2851-H with Horizontal Tailpiece 68.00 62.00 56.50
† 2851-V with Vertical Tailpiece 68.00 62.00 56.50
† 2851-L with Lazy-motion Tailpiece 68.00 62.00 56.50
Twin Low & Twin Low 600 Series Classic
Low
600 Description HD HT BL BD COMP SUB —
L651-H 651-H with Horizontal Tailpiece 84.00 75.00 —
L651-V
651-V with Vertical Tailpiece 84.00 75.00 —
L651-L 651-L w/Lazy-motion Tailpiece 84.00 75.00 —
Mortise Cylinder Key:
HD
– Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
R – Retainer
1.366 0.138 1.290 0.060
1.366 0.138 1.290 0.060
1.366 0.138 1.290 0.060
1.366 0.138 1.290 0.060
1.366 0.138 1.290 0.060
1.366 0.138 1.290 0.060
1.366 0.138 1.290 0.060
1.366 0.138 1.290 0.060
1.366 0.138 1.290 0.060
1.366 0.138 1.290 0.060
1.366
0.138
1.290
0.060
1.366 0.138 1.290 0.060
1.366
0.138 1.290 0.060
1.366
0.138
1.290 0.060
1.366 0.138 1.290 0.060
1.366 0.138 1.290 0.060
1.366 0.138 1.290 0.060
1.366 0.138 1.290 0.060
1.366
0.138
1.290
0.060
1.366 0.138 1.290 0.060
1.366
0.138
1.290
0.060
H/V
L
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 8851-H x CLIQ x 626 x Sidebar x Comp
† Available in special function cylinders, see page 10, add $29.00.
