ASSA Rim Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Rim Cylinders
BL
HT
R
HD
Available Tailpieces
Mortise Cylinder Key:
HD
– Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
R – Retainer
H/V
L
Corbin Jumbo Rim Cylinder
Model/TP# Description HD HT BL R Comp Sub SNS
T
win V-10
† V7551-H with Horizontal Tailpiece 155.50 148.00 141.00
† V7551-V with Vertical Tailpiece 155.50 148.00 141.00
† V7551-L with Lazy-motion Tailpiece 155.50 148.00 141.00
Twin Exclusive
† E7551-H with Horizontal Tailpiece 155.50 148.00 141.00
† E7551-V with Vertical Tailpiece 155.50 148.00 141.00
† E7551-L with Lazy-motion Tailpiece 155.50 148.00 141.00
Twin 6000 Classic
† 7551-H with Horizontal Tailpiece 137.50 128.50 119.50
† 7551-V with Vertical Tailpiece 137.50 128.50 119.50
† 7551-L with Lazy-motion Tailpiece 137.50 128.50 119.50
Twin Pro
† 7151-H with Horizontal Tailpiece 155.50 148.00 141.00
† 7151-V with Vertical Tailpiece 155.50 148.00 141.00
† 7151-L with Lazy-motion Tailpiece 155.50 148.00 141.00
Twin Maximum
† 7851-H with Horizontal Tailpiece 155.50 148.00 141.00
† 7851-V with Vertical Tailpiece 155.50 148.00 141.00
† 7851-L with Lazy-motion Tailpiece 155.50 148.00 141.00
Twin Low & Twin Low 600 Series Classic
Low 600 Description HD HT BL BD COMP SUB —
L651-H 651-H with Horizontal Tailpiece 121.00 112.00 —
L651-V
651-V
with V
ertical Tailpiece 121.00 112.00 —
L651-L 651-L w/Lazy-motion Tailpiece 121.00 112.00 —
1.643 0.170 1.270 0.060
1.643 0.170 1.270 0.060
1.643 0.170 1.270 0.060
1.643 0.170 1.270 0.060
1.643 0.170 1.270 0.060
1.643 0.170 1.270 0.060
1.643 0.170 1.270 0.060
1.643 0.170 1.270 0.060
1.643 0.170 1.270 0.060
1.643 0.170 1.270 0.060
1.643
0.170
1.270
0.060
1.643 0.170 1.270 0.060
1.643
0.170 1.270 0.060
1.643
0.170
1.270 0.060
1.643 0.170 1.270 0.060
1.643 0.170 1.270 0.060
1.643 0.170 1.270 0.060
1.643 0.170 1.270 0.060
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 7851-H x CLIQ x 626 x Sidebar x Comp
† Available in special function cylinders, see page 10, add $29.00.
