61
ASSA Interchangeable Cores
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise and Rim IC Cylinders
BL
HT
BD
HD BH
CBL
BW
R
Available Cams
#12 #13 #15
#1 #2 #3 #4
#5
#6 #7 #8
#9 #10
Mortise Cylinder Key:
HD
– Head Diameter • HT – Head Thickness
BL – Body Length (Includes Cam) • BD – Body Diameter
BH – Body Height • BW – Body Width • R – Retainer
CBL – IC Core Body Length
Cam Key:
R-A
– Head Radius • R-B – Overall Radius
Tailpieces
H/V
L
1-1/4" Mortise Cylinder
Mod/Cam# Description HD HT BL BD BH BW CBL R R-A R-B Comp Sub SNS
Twin Pro
6152IC-1 with Adams Rite Cam 120.50 113.00 106.00
6152IC-2 with Sargent Cam 120.50 113.00 106.00
6152IC-3 with Cor. Clover Leaf Cam 120.50 113.00 106.00
6152IC-4 with Cor. Beaver Tail Cam 120.50 113.00 106.00
6152IC-5 with Yale Standard Cam 120.50 113.00 106.00
6152IC-6 with Schlage “L” Cam 120.50 113.00 106.00
6152IC-7 with Segal Type Cam 120.50 113.00 106.00
6152IC-8 with Corbin Jumbo Cam 120.50 113.00 106.00
6152IC-9 with Best 30H Cam 120.50 113.00 106.00
6152IC-10 with Norment/AirTeq Cam 120.50 113.00 106.00
6152IC-12 w/ Cor. Jumbo Clover Leaf 120.50 113.00 106.00
6152IC-13 with Sargent Short Cam 120.50 113.00 106.00
6152IC-15 with Yale Rep. Cam 120.50 113.00 106.00
Twin Maximum
8852IC-1 with Adams Rite Cam 120.50 113.00 106.00
8852IC-2 with Sargent Cam 120.50 113.00 106.00
8852IC-3
with Cor
. Clover Leaf Cam
120.50
113.00 106.00
8852IC-4 with Cor. Beaver Tail Cam 120.50 113.00 106.00
8852IC-5
with Y
ale Standar
d Cam
120.50 113.00 106.00
8852IC-6
with Schlage “L” Cam
120.50 113.00 106.00
8852IC-7 with Segal Type Cam 120.50 113.00 106.00
8852IC-8 with Corbin Jumbo Cam 120.50 113.00 106.00
8852IC-9 with Best 30H Cam 120.50 113.00 106.00
8852IC-10 with Norment/AirTeq Cam 120.50 113.00 106.00
8852IC-12 w/ Cor. Jumbo Clover Leaf 120.50 113.00 106.00
8852IC-13
with Sar
gent Shor
t Cam
120.50
113.00
106.00
8852IC-15 with Yale Rep. Cam 120.50 113.00 106.00
Twin Maximum Medium Security
2852IC-1 with Adams Rite Cam 96.50 90.50 84.50
2852IC-2 with Sargent Cam 96.50 90.50 84.50
2852IC-3 with Cor. Clover Leaf Cam 96.50 90.50 84.50
2852IC-4
with Cor
. Beaver T
ail Cam
96.50
90.50
84.50
2852IC-5 with Yale Standard Cam 96.50 90.50 84.50
2852IC-6 with Schlage “L” Cam 96.50 90.50 84.50
2852IC-7
with Segal Type Cam 96.50 90.50 84.50
2852IC-8 with Corbin Jumbo Cam 96.50 90.50 84.50
2852IC-9 with Best 30H Cam 96.50 90.50 84.50
2852IC-10 with Norment/AirTeq Cam 96.50 90.50 84.50
2852IC-12
w/ Cor
. Jumbo Clover Leaf
96.50
90.50
84.50
2852IC-13 with Sargent Short Cam 96.50 90.50 84.50
2852IC-15
with Y
ale Rep. Cam
96.50
90.50
84.50
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 8852IC-1 x CLIQ x 626 x Sidebar x Comp. For temporary cores refer to Red Core on page 4.
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.118 0.555
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.709
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.114 0.602
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.732
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.709
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.124 0.516
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.779
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.914
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.114 0.602
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.787
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.114 0.828
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.515
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.742 0.308
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.118 0.555
1.366
0.175
1.125
1.157 1.055 0.655 1.247 0.036 N/A 0.709
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.114 0.602
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.732
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.709
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.124 0.516
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.779
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.914
1.366
0.175
1.125 1.157 1.055 0.655 1.247 0.036 0.114 0.602
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.787
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.114 0.828
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.515
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.742 0.308
1.366
0.175
1.125 1.157 1.055 0.655 1.247 0.036 0.118 0.555
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.709
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.114 0.602
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.732
1.366
0.175
1.125
1.157
1.055
0.655
1.247
0.036
N/A 0.709
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.124 0.516
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.779
1.366
0.175
1.125
1.157
1.055 0.655 1.247 0.036 N/A 0.914
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.114 0.602
1.366
0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.787
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.114 0.828
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.515
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.742 0.308
