60
ASSA Interchangeable Cores
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise and Rim IC Cylinders
BL
HT
BD
HD BH
CBL
BW
R
Available Cams
#12 #13 #15
#1 #2 #3 #4
#5
#6 #7 #8
#9 #10
Mortise Cylinder Key:
HD
– Head Diameter • HT – Head Thickness
BL – Body Length (Includes Cam) • BD – Body Diameter
BH – Body Height • BW – Body Width • R – Retainer
CBL – IC Core Body Length
Cam Key:
R-A
– Head Radius • R-B – Overall Radius
Tailpieces
H/V
L
1-1/4" Mortise Cylinder
Mod/Cam# Description HD HT BL BD BH BW CBL R R-A R-B Comp Sub SNS
Twin V-10
V6552IC-1 with Adams Rite Cam 120.50 113.00 106.00
V6552IC-2 with Sargent Cam 120.50 113.00 106.00
V6552IC-3 with Cor. Clover Leaf Cam 120.50 113.00 106.00
V6552IC-4 with Cor. Beaver Tail Cam 120.50 113.00 106.00
V6552IC-5 with Yale Standard Cam 120.50 113.00 106.00
V6552IC-6 with Schlage “L” Cam 120.50 113.00 106.00
V6552IC-7 with Segal Type Cam 120.50 113.00 106.00
V6552IC-8 with Corbin Jumbo Cam 120.50 113.00 106.00
V6552IC-9 with Best 30H Cam 120.50 113.00 106.00
V6552IC-10 with Norment/AirTeq Cam 120.50 113.00 106.00
V6552IC-12 with Cor. Jumbo Clover Leaf 120.50 113.00 106.00
V6552IC-13 with Sargent Short Cam 120.50 113.00 106.00
V6552IC-15 with Yale Rep. Cam 120.50 113.00 106.00
Twin Exclusive
E6552IC-1 with Adams Rite Cam 120.50 113.00 106.00
E6552IC-2 with Sargent Cam 120.50 113.00 106.00
E6552IC-3
with Cor
. Clover Leaf Cam
120.50
113.00 106.00
E6552IC-4 with Cor. Beaver Tail Cam 120.50 113.00 106.00
E6552IC-5
with Y
ale Standar
d Cam
120.50 113.00 106.00
E6552IC-6
with Schlage “L” Cam
120.50 113.00 106.00
E6552IC-7 with Segal Type Cam 120.50 113.00 106.00
E6552IC-8 with Corbin Jumbo Cam 120.50 113.00 106.00
E6552IC-9 with Best 30H Cam 120.50 113.00 106.00
E6552IC-10 with Norment/AirTeq Cam 120.50 113.00 106.00
E6552IC-12 with Cor. Jumbo Clover Leaf 120.50 113.00 106.00
E6552IC-13
with Sar
gent Shor
t Cam
120.50
113.00
106.00
E6552IC-15 with Yale Rep. Cam 120.50 113.00 106.00
Twin 6000 Classic
6552IC-1 with Adams Rite Cam 142.00 132.00 124.00
6552IC-2 with Sargent Cam 142.00 132.00 124.00
6552IC-3 with Cor. Clover Leaf Cam 142.00 132.00 124.00
6552IC-4
with Cor
. Beaver T
ail Cam
142.00
132.00
124.00
6552IC-5 with Yale Standard Cam 142.00 132.00 124.00
6552IC-6 with Schlage “L” Cam 142.00 132.00 124.00
6552IC-7
with Segal Type Cam 142.00 132.00 124.00
6552IC-8 with Corbin Jumbo Cam 142.00 132.00 124.00
6552IC-9 with Best 30H Cam 142.00 132.00 124.00
6552IC-10 with Norment/AirTeq Cam 142.00 132.00 124.00
6552IC-12
with Cor
. Jumbo Clover Leaf
142.00
132.00
124.00
6552IC-13 with Sargent Short Cam 142.00 132.00 124.00
6552IC-15
with Y
ale Rep. Cam
142.00
132.00
124.00
For temporar
y cor
es refer to Red Core on page 4.
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.118 0.555
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.709
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.114 0.602
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.732
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.709
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.124 0.516
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.779
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.914
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.114 0.602
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.787
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.114 0.828
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.515
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.742 0.308
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.118 0.555
1.366
0.175
1.125
1.157 1.055 0.655 1.247 0.036 N/A 0.709
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.114 0.602
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.732
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.709
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.124 0.516
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.779
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.914
1.366
0.175
1.125 1.157 1.055 0.655 1.247 0.036 0.114 0.602
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.787
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.114 0.828
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.515
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.742 0.308
1.366
0.175
1.125 1.157 1.055 0.655 1.247 0.036 0.118 0.555
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.709
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.114 0.602
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.732
1.366
0.175
1.125
1.157
1.055
0.655
1.247
0.036
N/A 0.709
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.124 0.516
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.779
1.366
0.175
1.125
1.157
1.055 0.655 1.247 0.036 N/A 0.914
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.114 0.602
1.366
0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.787
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.114 0.828
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 N/A 0.515
1.366 0.175 1.125 1.157 1.055 0.655 1.247 0.036 0.742 0.308
