D6001DE-R Double Unit Series (Double Egress) Power Operator
Technical Data
Input power: 120VAC, 60Hz
Power consumption: .9 amps
Circuit breaker: 3 amps
Power supply: 24 V DC, max. 2.2 amp.
Door width: 36" - 48" (91-122 cm)
Door weight: 100-250 lb. (43-113 kg)
Door opening angle: up to 110° with reveal of 3" (7.6 cm) max
Hold open time: 0-30 seconds (A.D.A. 5 seconds min.)
Indenite for optional Innite Hold Open
Notes:
• Permanent wiring is to be implemented as
required by local codes.
• Activation devices: push plates, access control,
mats, touchless wall switches, etc.
• Maximum wire size is:
12AWG at terminals LINE and NEUTRAL
(120VAC; 60Hz) on Power Input Terminal
mounted on inside of end cap.
14AWG at all other terminals
• Rate of operation shall not exceed 300 cycles of
opening and closing per hour.
Before You Begin
• All dimensions are given in inches.
DO NOT scale drawings.
• Thickness recommended for reinforcements
in hollow metal doors and frames is charted.
• This template information based upon use of
5" maximum width butt hinges.
• Frame reveal is 2-1/4" to 4-3/4" for push arm
and 1/8" to 3" for pull arm.
• Before beginning the installation, verify that
the door frame is properly reinforced and is
well anchored in the wall. Frame header must
be straight - without warp or bow.
• Unreinforced hollow metal frames and
aluminum frames should be prepared and
tted with 1/4-20 blind rivet nuts, furnished
by others.
• Concealed electrical conduit and concealed
switch or sensor wires should be pulled to
the frame before proceeding.
1/8"
(3)
Door
Frame
Hollow Metal Door Frame Reinforcing
Frame Material
Reinforcing
Recommended Min. Required
12 Ga.
.105
(2.66)
12 Ga.
.105
(2.66)
18 Ga.
.048
(1.21)
14 Ga.
.075
(1.90)
10 Ga.
.134
(3.41)
12 Ga.
.105
(2.66)
16 Ga.
.060
(1.52)
10 Ga.
.134
(3.41)
12 Ga.
.105
(2.66)
18 Ga.
.048
(1.21)
8 Ga.
.164
(4.18)
10 Ga.
.134
(3.41)
Fasteners for Frame:
• 1/4-20 Machine screws for
hollow metal and aluminum.
• No. 14 x 2-3/4" (70mm) long
sheet metal screws for wood.
Templating based on 1/8" gap
between door and frame.
Mounting Hardware Door or Frame Drill
Backplate:
14 x 1-1/2 Flat Head Self Drilling Screw
Wood 3/16" (4.76mm)
Backplate:
1/4-20 x 1 Flat Head Machine Screw
Metal
Drill #7 (.201 dia. or 5.10mm)
Tap 1/4-20
Backplate:
1/4-20 x 5/8 Flat Head Machine Screw
Track:
Sex Nut and Bolt (SNB)
(optional)
Hollow Metal
9/32" (7.00mm) thru
3/8" (9.50mm) door face opposite to closer
Aluminum or Wood 3/8" (9.50mm) thru
