Assa Abloy PTI AP1 - Specifications

USER MANUAL
Page - 4
AP1 KEYPAD
Electrical Specications:
Input Voltage: 12 to 48V DC supplied by a Class 2 current limited
source
Power Consumption: < 2.5W estimate (does not include keypad heater)
Communication: 2-wire RS485 at 9600 baud
Inputs: 2 with optional supervision using 1K resistors in
series, parallel or both.
Outputs: 2 relays rated at 2 A @ 30 Vdc resistive
Operating Temperature: -40 to +85 C (-40 to 185F)
Humidity: TBD
Ingress Protection IP65 (PENDING) – requires proper mounting.
Heater (optional) 14 VDC max power input, 10W min output
capability.
Regulatory:
Bluetooth SIG Declaration ID: D067838
FCC ID 2BFJY-1000239
2BFJY-1000260
UL294
IC ID Non-heated AP1: 32223-1000239
Heated AP1: 32223-1000260
CE
| SPECIFICATIONS
