7
Control Functions
A LED
When the coool blue LEDis lit, the SET-300B is “ON”,
receiving power from the power supply.
B ON-OFF button
When in the ON position (button depressed), high
voltage power is received by the SET-300B circuitry
f rom the power source. Due to the warm up
characteristics of tubes, it will take 30 seconds for the
tubes to pass full signal. It is suggested that the
SET-300B remain muted or the volume control on the
preamp be turned down for this first minute. When in
the OFF position (not depressed), the SET-300B is not
receiving power and is not operational.
Connection Functions
C Detachable AC Power Cord Socket
Plug the Detachable Power Cord into this socket.
D Speaker Connection Posts
These 5-way binding posts accept a connection from
one pair of speakers. The negative connections are to
be made to the black connectors; left speaker to the
terminals marked left and right to the terminal marked
right.
E Preamplifier Input
This input accepts RCA input connections from an
external preamp or crossover; connect left channel to
left channel and right channel to right channel.
F Mute/Operate Switch
The input of the 300B may be muted via this switch.
This is handy when changing interconnect cables or
even isolating system components for tro u b l e
shooting purposes.
G Optional Set - Control
This level control may a switched attenuator or
potentiometer from TPC or one of your own favorites.
This will allow a source device to be dire c t l y
connected to the amplifier input jacks there b y
bypassing an outboard preamp.
WARNING - DISCONNECT T H E AC D E TAC H A B L E
P OW E RC O R DF RO MT H ES E T- 3 0 0 B AND WAIT 5
MINUTES BEFORE REMOVING BOT TOM COV E R ,
TUBES OR FUSE.
