Associated Electrics RC10 B4.2 - CVA and Turnbuckle Assembly

11
:: Rear End Build - Bag E-EE - Step 6
:: CVA and Turnbuckles Build - Bag F-FF - Step 1
:: CVA and Turnbuckles Build - Bag F-FF - Step 2
Build x2 (right and left side)
1 drop!
CA glue not
included
Align the gap in
the pin retainer
to be opposite of
the CVA pin.
!
#1597
ca glue
Build x2
3977
3/16x3/8
bearing
9864
FT aluminum
hub ( 0˚)
4449
4-40x3/16
aluminum
locknut
6272
Dust cover
foam
7933
Crush tube
3981
Ballstud, .20
black, short
9917
Aluminum
hub A,
carbon
7935
.187x.196
bearing
7368
3/16 axle
shim
Left Side
7381
CVA coupler
7996
CVA pin
retainer
9755
CVA axle
rear
9672
CVA bone
7381
CVA cross
pin
#6588
black grease
6288
4-40x1/4
bhcs
x2
6924
4-40x3/8
shcs
6915
4-40x5/8
fhcs
x2
x2
