Associated Electrics RC10 B4.2 - Transmission Assembly

6
:: Front End, Inner Build - Bag C - Step 2
:: Front End, Inner Build - Bag C - Step 3
:: Transmission Build - Bag D-DD - Step 1
Front Camber Turnbuckle
1.26” (32.00mm)
1.44” (36.50mm)
Steering Turnbuckle
Orient the notch
to the left
throughout the
car. It indicates
which end has the
left hand threads!
!
7230
ball cup
(large)
7666
Drive
rings
9852
Ball diff
outdrives
9852
Ball diff
outdrives
7666
Drive
rings
7230
ball cup
(large)
1406
2.00”
turnbuckle
1406
2.00”
turnbuckle
91311
4-40x7/8
bhcs
9568
B4 front
shock tower
1780
FT aluminum
shock bushings,
standard
6924
4-40x3/8
shcs
6277
Ballstud .30
silver, long
6581
3/32 carbide
diff balls
7664
Diff gear
52T
x2
x4
x2
x12
x2
x2
x2
x2
Ball diff
outdrives
rings
31286
FT ballstud
washer,
aluminum
(2mm)
6272
Dust cover
foam
x2
#6591
diff lube
#6591
diff lube
#6591
diff lube
#1596
thread lock
