Associated Electrics RC10 B4.2 - Shock Assembly

12
:: CVA and Turnbuckles Build - Bag F-FF - Step 3
:: CVA and Turnbuckles Build - Bag F-FF - Step 4
:: Shocks Build - Bag G-GG - Step 1
7369
1/16
roll pins
9890
12mm aluminum
clamping wheel
hex, buggy rear
Build x2 (right and left side)
Build x2
(right and left side)
Build x2 (right and left side)
1/16
roll pins
12mm aluminum
clamping wheel
hex, buggy rear
Orient the notch
to the left
throughout the
car. It indicates
which end has the
left hand threads!
!
91308
12mm shock
piston
(1.6 front)
(1.6 rear)
91305
21x3 TiN
shock shaft
(front)
91306
27.5x3 TiN
shock shaft
(rear)
6299
1/8 E-clip
6299
1/8 E-clip
4187
Nylon spacer,
(.030)
Racers Tip:
Use a marker over the
numbers on the pistons to
make them easily visible!
!
Front:
3 spacers
Rear:
2 spacers
9898
2-56x3/16
shcs
9645
2-56x1/8
bhcs
31286
FT ballstud
washer,
aluminum
(1mm)
9622
Hinge pin,
rear outer
9630
.030 ballstud
washer
Rear Camber Turnbuckle
1.28” (32.25mm)
7230
ball cup
(large)
1406
2.00”
turnbuckle
x2
