Associated Electrics RC8B3.2e - Page 10

10
:: :: Steering / Chassis Steering / Chassis BuildBuild - Bag - Bag 4.1, 4.24.1, 4.2 -- Step 2Step 2
:: :: Steering / Chassis Steering / Chassis BuildBuild - Bag - Bag 4.1, 4.24.1, 4.2 -- Step 3Step 3
8680
5x8x2.5mm
Bearing
x4x4
81084
Servo
Saver
Tube
81084
Servo Saver
Tube Shim
31404
6x10x3mm
Bearing
81083
Servo
Saver
Spring
1.5mm
81086
Servo
Saver Arm
81084
Servo Saver
Tube Spring
Nut & O-Ring
81086
Steering
Bellcrank
81086
Steering
Bellcrank
x2x2
x4x4
Racer’s Tip:
Use black grease
(#6588) to lube
the bellcrank halves
before installation!
:: :: Steering / Chassis Steering / Chassis BuildBuild - Bag 4.1, 4.2 - Bag 4.1, 4.2 -- Step 1Step 1
#6588
black grease
#1596
thread lock
81091
Steering
Post
81262
4x10mm
FHCS
x2x2
x2x2
81460
RC8B3.2e
Chassis
81431
RC8B3.2
Side
Guards
25201
3x8mm
FHCS
31540
3x5mm
FHCS
x8x8
x2x2
Loosely attach
3x5mm FHCS and
then install 3x8mm
FHCS. Tighten after
all screws are installed
(not included)
