Associated Electrics RC8B3.2e - Page 12

12
:: :: Front Gearbox Front Gearbox BuildBuild - Bag 5.1, 5.2, 5.35.1, 5.2, 5.3 -- Step 4
:: :: Front Gearbox Front Gearbox BuildBuild - Bag - Bag 5.1, 5.2, 5.35.1, 5.2, 5.3 -- Step 5Step 5
Kit Setup:
:: :: Front Gearbox Front Gearbox BuildBuild - Bag - Bag 5.1, 5.2, 5.35.1, 5.2, 5.3 -- Step 3Step 3
81260
4x14mm
BHCS
x2x2
81050
Arm Mount
Insert,
Center
81292
RC8B3 Arm
Mount B,
HRC
x2x2
Kit Setup:
Kit Setup:
81150
Anti-Roll
Bar Pivot
81150
Anti-Roll
Bar Rod
End
81150
Rod End
Ball
81258
3x12mm
Set Screw
x2x2
Left Side Right Side
Anti-Roll Bar Pivots:
Offset the anti-roll bar
rod ends
(approximately 45 degrees).
!
1.5mm
Build left and
right side!
Note direction
!
81260
4x14mm
BHCS
x2x2
81050
Arm Mount
Insert, Center
x2x2
x2x2
x2x2
81291
RC8B3
Arm Mount
A, HRC
81060
Hinge
Pin
89317
Droop
Screw
81446
Suspension
Arm Shim
81438
Front Arm,
Lower
81438
Front Arm
Insert,
Lower
!
Note that each arm is
marked with a R for the
Right arm or an L for
the Left arm.
25201
3x8mm
FHCS
x5x5
81197
Shock
Pin
81257
3x6mm
Set Screw
x2x2
x2x2
Take care not to
overtighten
insert screws.
!
Droop Screw:
Kit Setup:
4.0mm
