16
:: :: Rear End Build - Bag 7.1, 7.2, 7.3 - Step 3Rear End Build - Bag 7.1, 7.2, 7.3 - Step 3
81260
4x14mm
BHCS
x2x2
81050
Arm Mount
Insert,
Center
81454
Arm Mount,
HRC, Narrow
(C)
x2x2
Kit Setup:
:: :: Rear End Build - Bag 7.1, 7.2, 7.3 - Step 2Rear End Build - Bag 7.1, 7.2, 7.3 - Step 2
25620
3x10mm
SHCS
25201
3x8mm
FHCS
81434
Rear Arm
Insert
81434
Rear Arm
81381
Diff Shim
13.5x15.8x0.20mm
x2x2
x3x3
x5x5
81015
Gearbox,
(Outboard)
81015
Anti-Roll
Bar Cap
81259
2.5x18mm
BHCS
STEP 1
STEP 2
!
!
NOTE:
Install the REAR Diff!
#6588
black grease
:: :: Rear End Build - Bag 7.1, 7.2, 7.3 - Step 1Rear End Build - Bag 7.1, 7.2, 7.3 - Step 1
89221
5x4mm
Set Screw
81021
Center
Universal,
(106mm)
81015
Gearbox,
(Inboard)
81015
Dust Cap
91561
6x12x4mm
Bearing
4675
2.5x6mm
FHCS
81009
Diff Pinion
Gear, 12T
x2x2
#1596
thread lock
Racer’s Tip:
Use black grease
(#6588) to
lube the diff pinion
before installation!
!
Note that each
arm is marked
with a R for the
Right Arm or an L
for the Left Arm.
89317
Droop
Screw
Take care not to
overtighten
insert screws.
!
Step 1:
Add shims on the ring gear
side to TIGHTEN gear mesh.
Subtract shims on this side
to LOOSEN gear mesh.
Step 2:
Add or subtract shims here
to finalize diff side to side
play once gear mesh is
set from Step 1.
Recommended diff side to
side clearance (gearbox
assembly) 0.10 - 0.25mm.
Notes:
0.1mm shim can be used for
fine tuning of gear mesh
Droop Screw:
Kit Setup:
1.5mm
(not included)
To Next Page
