© Associated Research 2017
82
Appendix C - Options
Introduction
This section contains a list and descriptions of available factory installed options at the time of this printing. The list of options
contains an option code number which can be referenced on the model option label on the rear panel of the unit when options
are present.
Model Option Label
On the rear panel of the instrument, you will nd a label that contains the option code.
For example, your options code will appear as follows:
tted with option 01 OPT: 01
tted with option 01 and 02 OPT: 0102
HypotULTRA Options
CODE DESCRIPTION
01 Internal 8 Channel Scanner with Continuity (7820 & 7850 only)
02 Internal 4 Channel Scanner with Continuity (7820 & 7850 only)
04 3mA AC/DC Output (7804, 7820 & 7850 only)
05 5mA AC/DC Output (7804, 7820 & 7850 only)
07 Printer Port (all models)
08 GPIB Card (all models)
09 Ethernet Card (all models)
10 Burn Hipot Test (7820, 7850 & 7804 only)
11 Continuity Delay Timer (7820 & 7850 only)
12 Negative DCW (7850, 7800, 7804, 7854)
13 400/800 Hz AC Hipot Output (7820, 7850 & 7804 only)
14 Mimic HU3 Command Set (7820 & 7850 only)
