REFERENCE # 450519
06/19/03Rev. 0
Upper Assembly 1200LS/SS
JCI 24/7 Parts Number 888-474-0115
© 2003 JCI
PAGE 3
ITEM QTY
PART
NUMBER
DESCRIPTION COMMENTS
1 1 4 5 0 0 4 2 B O N N E T
2 1 4 5 0 2 2 1 B O N N E T S U P P O R T
3 8 450055 PRESSURE ROD
4 4 087001 VALVE, RELIEF, 3/8
5 4 450130 WEDGE, BOWL, CASTING
6 4 0 7 6 0 11 N U T, J A M , A D J U S T I N G J A C K
7 8 450006 FLUID CONNECTOR
8 32 080007 O-RING, 2-012
9 1 450065 MANIFOLD BLOCK
10 1 540166 ACCUMULATOR, 1 GAL 1-1/4NPT
11 8 450109 CLAMP CYLINDER ASSEMBLY
12 4 450116 ADJUSTING JACK ASSEMBLY
13 1 082012 HOSE 1/4X 12IN - 04MB X 04MC
14 2 083019 MALE BRANCH TEE, 1/4
15 2 083018 C2404-04-04, MALE CONN TU 1/4
16 4 083017 C2501-04-04, MALE ELBOW T 1/4
17 8 450044 DUST COVER, RELIEF CYLINDER
18 4 083038 PVV-14-F, COUPLER QUICK DISC F
19 4 083051 TMP-14, 1/4 DUST PLUG
20 168 081001 TUBING, 1/4 X .049 WALL
21 4 450218 ROTATION STOP PIN - 1200
22 4 450217 LOWER ROTATION STOP - BOLT ON
23 8 450216 PRESS RING BOLT SOLID MANIFOLD
24 2 540168 ACCUM, 5 GAL 1-7/8-12UN, SPLI
25 1 450511 RING BEAM RELIEF CYL-1200
26 8 450215 RELIEF CLY ASSEMBLY - 1200
27 2 540157 ACCUM BRACKET-5 GAL 180 DEG
28 12 540173 ACCUMULATOR BRACKET BLOCK
29 2 450222 ACCUM MOUNT M/BRACKET-1200
30 8 070180 "CAPSCREW HEX 1"" 8NC X 5 G8 ZIN"
31 8 078030 WASHER, HT, 1
32 2 083022 MALE ELBOW 1/4
33 2 083023 FLARELESS TUBE END CAP 1/4
34 1 083078 PIPE PLUG-1-1/4-PARK 1-1/4HP
35 6 083055 MOUNTING CLIP, 1/4 TUBE
36 8 083124 SPLIT FLANGE, 51H32
37 2 540203 ACCUMULATOR BRACKET, 1 GALLON
38 16 084016 O-RING 6230-12
39 32 070107 CAP SCREW HEX 3/4 10NC X 4-1/2
