ASTEC JCI LS Series User Manual

REFERENCE # 450519
06/19/03Rev. 0
Upper Assembly 1200LS/SS
JCI 24/7 Parts Number 888-474-0115
© 2003 JCI
PAGE 4
40 2 070086 CAP SCREW HEX 5/8 11NC X 5 G5
41 10 070134 CAP SCREW HEX 5/8 11NC X 6 G5
42 4 070014 CAP SCREW HEX 5/8 11NC X2-1/2
43 38 076001 NUT, NYLOCK 5/8-11 NC
44 16 076040 NUT HEAVY HEX JAM 2-1/4X4-1/2
45 6 070055 CAP SCREW HEX 1/4 20NC X 3/4
46 2 070080 CAP SCREW HEX 5/8-11NC X3-1/2
47 9 051006 FB .250 X 1.500
48 32 078026 WASHER, LOCK, 3/4
49 2 090063 OAKUM, DARK
50 8 540236 ANGLE CLIP, 2 X 2 X 3/8
51 20 078000 WASHER, HT, .625
52 4 540303 ACCUM BRKT HD BOLT CLAMP
53 2 450301 ACCUMULATOR BRACKET
54 2 540304 ACCUM BRKT 5 GAL BOTTOM
55 4 070151 SETSCREW 1/2-13NC X 3/4 SOC HD
56 6 078022 WASHER, LOCK, 1/4
57 4 450302 CAP ROT STOP PLG CCF2 1/2-8-12
58 4 084069 O-RING 2-228 32 SPLIT FLANGE
59 8 070415 CAPSCREW HEX 1/2 13NC X 5-1/2
60 8 078025 WASHER, LOCK, 1/2
61 20 070038 CAP SCREW HEX 5/8 11NC X2G5
62 1 450520 HOPPER, 1200LS
63 4 070016 CAP SCREW HEX 1/2 13NC X1-1/2
64 4 076005 NUT NYLOCK 1/2-13NC
65 2 450518 TUBE ASSEMBLY WELDMENT, 1200
66 2 450521 HOSE, ACCUMULATOR, SEE TEXT
68 2 088203 5151HK-24, SAE FLANGE KIT-24
ITEM QTY
PART
NUMBER
DESCRIPTION COMMENTS
