Astralpool 78543 - Mode and Temperature Settings

Operation and use
2. Color screen wire controller function introduction
2.1 Booting and shutdown
As shown in figure 1.1:
In shutdown status, click then the unit will be booted
In booting status, click then the unit will be shut
down.
2.2 Mode switch and target temperature Setting
2.2 1 Mode switch
In the main interface, click mode button or inlet water temperature setting
button, interface displays as follows:
28.0
Click the refrigeration mode button , automatic mode or
heating mode button then you can select the corresponding mode.
Note: when the unit is designed for single automatic mode or single
thermal mode, the mode can not be switched.
2.2 2Target temp. setting
Click the temperature set button , you can set the target temperature.
