Astralpool BPM800A - Page 9

Inst253 Astral Heat Pumps V07.13
9
Alarm
-
Alarm state
% The meaning of the LED display
The LED usually shows temperature, if it shows “SHr”, it means the temperature sensor is short, and
“OPE” means the temperature sensor is open. The temperature and the alarm code (Axx) will show
alternately when in the alarm state.
The code is showing below:
Code
Signification
Explanation
A11
External alarm
Low Pressure Alarm
A12
External alarm
High Pressure Alarm
A15
External alarm
Water Flow Alarm
A21
Water temperature sensor error
Open or short（showing “OPE” or “SHr”）
A22
Outdoor machine sensor error
Open or short（showing “OPE” or “SHr” when press the key “↓”）
A99
Over probation time
If you have set the probation time F87, the alarm occurs when the accumulative running
time is over probation time, and the controller can not work.
% How to set the temperature?
Press the key “set” for at least 2 seconds, then enter the state of temperature setting, here the LED
displays the setting temperature, then using “” key or “” key can change the parameter（the
key“”adds 0.1°C, the key“”minuses 0.1°C, press and hold it over 0.5 seconds can add or minus
rapidly）. After setting, press “set” again, then exit the state of parameter setting. (The setting temp
range is limited by the parameters F13 and F14, please refer to the advanced operation). Pressing the key
“M” in the setting process means cancel and exit, but the setting value will not be saved.
% How to read the outdoor temperature?
When displaying current temperature, press “” key, Controller will display defrosting temperature.
Loose “” key, then return to current temperature. Notice that if you press the key and hold it for 5
seconds, the controller will enter or exit the defrosting state forcibly.
% How to look over and adjust the real clock time?
Press the key “Set” to enter the state of displaying time when in the state of displaying temperature. Press
the key “Set” for some time to enter the state of adjusting time, and press the key “Set” to return to the
state of displaying temperature.
In the state of adjusting time, the hour part of the LED flashes, and you can adjust the hour by using the
key “” and “”, then press the key “Set”, and the minute part of the LED flashes, you can also use the
key “” and “” to adjust the value, then press the key “Set” again to exit. Pressing the key “M” in the
adjusting process means giving up and exiting, but the time will not be saved.
% How to heat forcibly?
When displaying current temperature, the temperature is between “setting temperature－temperature
difference” and “setting temperature＋temperature difference”, the system may or not heat, here you
press the key “” and hold it for 5 seconds, the controller will enter the heat state forcibly when in the
heat state, and stop heating when the temperature is above “setting temperature＋temperature
difference”.
& Advanced Operation
Press the key “M” and hold it for 5 seconds, and if you have set the password, the LED display the
“PAS” to hint you to enter the password, you can use the key “↑” and “↓” to enter the password, if the
password is correct, the LED will display the parameter code, use “↑” or “↓” to select the parameter code
，Pressing the “set” key can make it to show the value of the parameter after select the parameter, here
you use “↑” or “↓” to set the parameter(pressing the key and not release can add or minus rapidly), then
press the “set” key to return to the state of showing parameter code after finishing setting. Pressing the
key “M” can exit the parameter setting state when display the parameter code, pressing the key “M”
means cancel when in the process of setting parameter, and the parameter will not be changed.
Internal parameter code is showing below:
