CTX, XP, XF and E Series Pumps | Installation and Operation Manual
7
2.5 Dimensions
247mm
341mm
5x Pipe Diameter
273mm
609mm
295mm
216mm
Figure 1. CTX-Series Pump
5x Pipe Diameter
336mm
704mm
291mm
216mm
249mm
359mm
Figure 2. XP-Series Pump
423
346
160
77
268
135
295
250
Figure 3. XF-Series Pump
245mm
323mm
5x Pipe Diameter
273mm
219mm
295mm
Figure 4. E-Series Pump
