Astralpool PROELYXP16i - Page 46

- 53 -
9.6 Spare parts list: 71679
NO
ERP
Parts Name
NO
ERP
Parts Name
1
1330900291
Top cover
35
113712007
Waterproof controller box
2
117110020
Ambient temp. sensor T5-TH1
36
117020180
Controller
3
133020010
Ambient temp. sensor clip
37
103000220
Evaporator pipe
4
1330900271
Back panel
38
136020005
Rubber block
5
103000220
Evaporator
39
103000220
Distribution piping
6
117110004
Evaporator temperature sensor
T3-TH2
40
113030081
4-way valve to exchanger
7
113100009
Sensor holder
41
116000066
High pressure switch
8
113100009
Clip
42
116000071
Low pressure switch
9
108110038
Top frame
43
113010159
Discharge pipe
10
108110043
Fan motor bracket
44
117110021
Discharge temp. sensor T6-TH3
11
117230003
Reactor
45
113020321
Gas return piping
12
108480015
Evaporator heating resistor
support
46
121000006
4 way valve
13
108110004
Pillar
47
113060084
4-way valve to collective piping
14
142000079
Evaporator heating resistor
48
119000017
EEV
15
112000031
Fan motor
49
113080054
EEV to distribution piping
16
1330900261
Left side panel
50
113070041
Exchanger to EEV
17
108010024
Fan shaft cover
51
113900082
Water connection sets
18
132000015
Fan blade
52
112100021-1
Water flow switch
19
1330900251
Front panel
53
133020012
Red rubber ring
20
108010014
Fan grill
54
133020026
Rubber ring on water connection
21
108050073
Isolation panel
55
116000001
Sealing ring
22
113100008
Globe valve support
56
117110011
Water outlet temp. sensor T2-TH5
23
120000091
Globe Valve
57
108010025
Exchanger temperature sensor clip
24
142000074
Compressor heating resistor
58
102040710
Titanium heat exchanger
25
101000181
Compressor + damping feet
59
133020011
Blue rubber ring
26
101000181
Compressor + damping feet
60
117110012
Water inlet temp. sensor T1-TH6
27
108110044
Base tray
61
150000110
Drainage plug
28
108010065
Terminal Board
62
108050017
Electric box cover
29
133090028
Right panel
63
117100047
PCB
30
106000011
Pressure gauge
64
108110045
Electric box
31
136010004
Clip
65
117240002
Magnet ring
32
115000004
5-ways terminal block
66
117010095
Modbus module
33
1332500051
Terminal blocks plastic cover
67
117240003
Magnet ring
34
133030011
Wiring box
