Page 9
27. Press SET-UP Switch momentarily. This brings down the envelope.
28. Turn Press Vacuum ON.
Feeder is equipped with a Photoelectric
Sensor [#1, Fig. 11], which synchronizes
Feeder with Press and prevents jam-ups. In
case Press does not pick up an envelope,
Feeder will not send another envelope. This
acts as a built in jam detector. Feeder remains
neutral as long as an envelope covers
Photoelectric Sensor. To start feeding again,
turn Feeder Vacuum and Drive Motor OFF.
Correct problem on Press and/or Feeder.
Follow Steps 26-28 to start feeding again.
NOTE: Make sure Feeder is set up so envelopes are fed over Photosensor. Also,
make sure no foreign objects, (e.g. lint, paper) cover Photosensor. It is essential to
Feeder's operation that Photosensor “sees” an envelope.
TO START AND STOP FEEDING: Use Duplicator Pump Switch. DO NOT use
Feeder Power Switch. Feeder Power Switch should be turned “ON” when job is
started, and remains on until job is complete.
Press speed can be changed while Feeder is feeding envelopes. Electronic circuitry of
Envelope Feeder is designed to respond automatically to operational commands of Press.
WARNING: Any speed changes to Press should be done GRADUALLY. Rapid
changes of speed affect registration and may cause misfeeding.
