Table 9-2: RF Performance Table
Maximum transmit power (dBm)
per transmit chain
Receiver sensitivity
dBm per receive chain
802.11b 2.4GHz
1 Mbps
18.0
-93.0
11 Mbps
18.0
-87.0
802.11g 2.4GHz
6 Mbps
18.0
-90.0
54 Mbps
16.0
-73.0
802.11n HT20 2.4GHz
MCS0/8
18.0
-90.0
MCS7/15
14.0
-71.0
802.11n HT40 2.4GHz
MCS0/8
18.0
-87.0
MCS7/15
14.0
-68.0
802.11a 5GHz
6 Mbps
18.0
-90.0
54 Mbps
16.0
-73.0
802.11n HT20 5GHz
MCS0/8
18.0
-90.0
MCS7/15
14.0
-71.0
802.11n HT40 5GHz
MCS0/8
18.0
-87.0
MCS7/15
14.0
-68.0
802.11ac VHT20 5GHz
MCS0
18.0
-90.0
MCS9
12.0
-67.0
802.11ac VHT40 5GHz
MCS0
18.0
-87.0
MCS9
12.0
-62.0
802.11ac VHT80 5GHz
MCS0
18.0
-84.0
MCS9
12.0
-59.0
Note: Table shows the maximum hardware capabilities of the AP (excluding antenna and MIMO/MRC gain).
Actual maximum transmit power may be limited below these numbers to ensure compliance with local
regulatory requirements.
