Asus B85M-E/DASH E-Manual

ASUS B85M-E/DASH
1-3
1.2.4 Layout contents
Connectors/Jumpers/Slots/LED Page
1.
Serialportconnector(10-1pinCOM) 1-17
2. ATXpowerconnectors(24-pinEATXPWR,4-pinATX12V)
1-14
3.
CPUandchassisfanconnectors(4-pinCPU_FAN,4-pinCHA_FAN1/2) 1-16
4. Intel
®
LGA1150CPUsocket 1-3
5. DDR3DIMMslots 1-7
6. USB3.0connector(20-1pinUSB3_12)
1-19
7. Intel
®
B85SerialATA3.0Gb/sconnectors(7-pinSATA3G_1~2[black])
1-18
8. Intel
®
B85SerialATA6.0Gb/sconnectors(7-pinSATA6G_1~4[yellow])
1-17
9. Systempanelconnector(10-1pinF_PANEL)
1-18
10. Speakerconnector(4-pinSPEAKER)
1-16
11.
ClearRTCRAM(2-pinCLRTC) 1-11
12. USB2.0connectors(10-1pinUSB1112,USB1314)
1-19
13. TPMconnector(20-1pinTPM)
1-15
14. OnboardLED(SB_PWR)
1-20
15. LPTconnector(26-1pinLPT)
1-14
16. Chassisintrusionconnector(4-1pinCHASSIS)
1-20
17. Frontpanelaudioconnector(10-1pinAAFP)
1-15
1.3 Central Processing Unit (CPU)
ThismotherboardcomeswithasurfacemountLGA1150socketdesignedforthe4th
generationIntel
®
Core™i7/Core™i5/Core™i3,Pentium
®
andCeleron
®
processors.
B85M-E/DASH
B85M-E/DASH CPU socket LGA1150
