2.4 Ai Tweaker menu
The Ai Tweaker menu items allow you to congure overclocking‑related items.
Be cautious when changing the settings of the Ai Tweaker menu items. Incorrect eld
values can cause the system to malfunction.
The conguration options for this section vary depending on the CPU and DIMM model you
installed on the motherboard.
Scroll down to display the following items:
Version 2.15.1231. Copyright (C) 2014 American Megatrends, Inc.
Version 2.15.1231. Copyright (C) 2014 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2014 American Megatrends, Inc.
Main Ai Tweaker Advanced Monitor Boot Tool Exit
CPU Core Ratio
→←:
Select Screen
↑↓:
Select Item
Enter: Select
+/-: Change Opt.
k/m: Scroll Help Text
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
→←:
Select Screen
↑↓:
Select Item
Enter: Select
+/-: Change Opt.
k/m: Scroll Help Text
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
Target CPU Turbo-Mode Speed: 3800MHz
Target DRAM Speed: 1333MHz
Target Cache Speed: 3800MHz
Target DMI/PEG Clock: 100MHz
Target CPU Graphics Speed: 1200MHz
Ai Overclock Tuner [Auto]
CPU Core Ratio [Auto]
Min. CPU Cache Ratio
Auto
Max. CPU Cache Ratio
Auto
BCLK Frequency:DRAM Frequency Ratio [Auto]
DRAM Frequency [Auto]
Max. CPU Graphics Ratio
Auto
GPU Boost [As Is]
EPU Power Saving Mode [Auto]
DRAM Timing Control
CPU Power Management
CPU Core Voltage [Auto]
CPU Cache Voltage [Auto]
CPU Graphics Voltage [Auto]
CPU
System
Agent
Voltage
Offset
Mode
Sign
[+]
CPU System Agent Voltage Offset Auto
CPU
Analog I/O Voltage
Offset
Mode
Sign
[+]
CPU Analog I/O Voltage Offset Auto
CPU
Digital I/O Voltage
Offset
Mode
Sign
[+]
CPU Digital I/O Voltage Offset Auto
SVID Control [Auto]
VCCIN Offset Mode Sign [+]
VCCIN Offset Voltage
Auto
DRAM Voltage Auto
DRAM CTRL REF Voltage Auto
DRAM DATA REF Voltage on CHA Auto
DRAM DATA REF Voltage on CHB Auto
CPU Spread Spectrum [Auto]
