Package contents
Check your motherboard package for the following items.
Motherboard
ASUS B85M-E/DASH motherboard
Cables
2 x Serial ATA 6.0 Gb/s cables
Accessories
1 x I/O Shield
Application DVD Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.
B85M-E/DASH specifications summary
CPU
LGA1150 socket for Intel
®
4th Generation Core
TM
i7/ Core
TM
i5 / Core
TM
i3,
Pentium
®
, and Celeron
®
Processors
Supports Intel
®
22nm CPU
Supports Intel
®
Turbo Boost Technology 2.0
* The Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset
Intel
®
B85 Express Chipset
Memory
4 x DIMM, max. 32GB, DDR3 1600 / 1333 / 1066 MHz, non-ECC, un-
buffered memory
Dual-channel memory architecture
* Refer to www.asus.com for the latest Memory QVL (Qualified Vendors List).
** Due to Intel
®
chipset limitation, the DDR3 1600MHz and higher memory modules
on XMP mode will run at the maximum transfer rate of DDR3 1600MHz.
*** When you install a total memory of 4GB capacity or more, Windows
®
32-bit
operating system may only recognize less than 3GB. We recommend a
maximum of 3GB system memory if you are using a Windows
®
32-bit operating
system.
Graphics
Integrated graphics processor
Multi-VGA output support: D-Sub, DVI-D, HDMI and DisplayPort ports
- Supports D-Sub with max. resolution of 1920 x 1200 @60Hz
- Supports DVI-D with max.resolution of 1920 x 1200 @60Hz
- Supports HDMI with max. resolution of 4096 x 2160 @24Hz / 2560 x
1600 @60Hz
- Supports DisplayPort with max. resolution of 4096 x 2160 @24Hz /
3840 x 2160 @60Hz
Maximum shared memory of 1024 MB
Expansion slots
1 x PCI Express 3.0/2.0 x16 slot
1 x PCI Express 2.0 x16 slot (@ x4)
1 x PCI Express 2.0 x1 slot
1 x PCI slot
Multi-GPU support
Supports ATI
®
CrossFireX™ Technology
