Asus B85M-K PLUS - Cpu Heatsink and Fan Assembly Installation

1-6
Chapter 1: Product introduction
1.3.2 CPU heatsink and fan assembly installation
To install the CPU heatsink and fan assembly
2
B
A
A
B
1
ApplytheThermalInterfaceMaterial
totheCPUheatsinkandCPU
before you install the heatsink and
fan if necessary.
3 4
