1.4 System memory
1.4.1 Overview
ThismotherboardcomeswithtwoDoubleDataRate3(DDR3)DualInlineMemoryModule
(DIMM)sockets.ADDR3moduleisnotcheddifferentlyfromaDDRorDDR2module.DO
NOTinstallaDDRorDDR2memorymoduletotheDDR3slot.
Channel Sockets
ChannelA DIMM_A1
ChannelB DIMM_B1
1.4.2 Memory configurations
Youmayinstall1GB,2GB,4GB,and8GBunbufferednon-ECCDDR3DIMMsintotheDIMM
sockets.
A
B
B
A
To uninstall the CPU heatsink and fan assembly
2
1
AccordingtoIntel
®
CPUspec,DIMMvoltagebelow1.65Visrecommendedtoprotectthe
CPU.
B85M-K PLUS
B85M-K PLUS 240-pin DDR3 DIMM sockets
DIMM_A1 DIMM_B1
