Asus B85M-K PLUS - Internal Connectors; Digital Audio Connector; Front Panel Audio Connector

ASUS B85M-K PLUS
1-15
1.7.2 Internal connectors
1. Front panel audio connector (10-1 pin AAFP)
Thisconnectorisforachassis-mountedfrontpanelaudioI/Omodulethatsupports
eitherHDAudioorlegacyAC`97audiostandard.Connectoneendofthefrontpanel
audioI/Omodulecabletothisconnector.
• Werecommendthatyouconnectahigh-denitionfrontpanelaudiomoduletothis
connectortoavailofthemotherboard’shigh-denitionaudiocapability.
• Ifyouwanttoconnectahigh-denitionfrontpanelaudiomoduletothisconnector,set
the Front Panel TypeitemintheBIOSsetupto[HD].IfyouwanttoconnectanAC’97
frontpanelaudiomoduletothisconnector,settheitemto[AC97].Bydefault,this
connectorissetto[HD].
TheS/PDIFmoduleispurchasedseparately.
2. Digital audio connector (4-1 pin SPDIF_OUT)
ThisconnectorisforanadditionalSony/PhilipsDigitalInterface(S/PDIF)port.Connect
theS/PDIFOutmodulecabletothisconnector,theninstallthemoduletoaslot
opening at the back of the system chassis.
B85M-K PLUS
B85M-K PLUS Front panel audio connector
AAFP
PIN 1
AGND NC SENSE1_RETUR SENSE2_RETUR
PORT1 L
PORT1 R PORT2 R
SENSE_SEND
PORT2 L
HD-audio-compliant
pin definition
PIN 1
AGND NC NC NC
MIC2
MICPWR
Line out_R
NC
Line out_L
Legacy AC’97
compliant definition
B85M-K PLUS
B85M-K PLUS Digital audio connector
SPDIF_OUT
+5V SPDIFOUT GND
