ASUS CUSL2-C User’s Manual 15
3. HARDWARE SETUP
3.2 Layout Contents
Motherboard Settings
1) JEN p.18 JumperFree™ Mode (Enable/Disable)
2) USBPWR01 p.19 USB Device Wake Up (Enable/Disable)
USBPWR2
USBPWR56
3) ADN# p.20 Onboard Audio CODEC (Enable/Disable)
4) KBPWR p.20 Keyboard Power Up (Enable/Disable)
5) VIO p.21 Voltage I/O Setting (3.3V/3.40V/3.60V)
6) DSW p.22 CPU External Frequency Setting
Expansion Slots
1) DIMM1/2/3 p.24 168-Pin System Memory Support
2) CPU p.26 Central Processing Unit (CPU)
3) PCI1/2/3/4/5/6 p.27 32-bit PCI Bus Expansion Slots
4) CNR1 p.28 Communication and Network Riser Slot
5) AGP p.29 Accelerated Graphics Port (AGP) Slot
Connectors
1) PS2KBMS p.30 PS/2 Mouse Connector (6-pin female)
2) PS2KBMS p.30 PS/2 Keyboard Connector (6-pin female)
3) USB p.31 Universal Serial Bus Ports (Two 4-pin female)
4) PRINTER p.31 Parallel Port Connector (25-pin female)
5) COM1/COM2 p.32 Serial Port Connectors (9-pin male, 10-1 pin)
6) GAME_AUDIO p.33 Game/MIDI Connector (15-pin female) (optional)
7) GAME_AUDIO p.33 Audio Port Connectors (Three 1/8” female) (optional)
8) FLOPPY p.33 Floppy Disk Drive Connector (34-1pins)
9) PRIMARY/SECONDARY IDE p.34 Primary/Secondary IDE Connectors (Two 40-1pins)
10) IDELED p.35 IDE Activity LED (2 pins)
11) CPU_FAN, PWR_FAN p.35 CPU, Power Supply, Chassis Fan Connectors (Three 3-pin)
CHA_FAN
12) CD1, AUX, p.36 Internal Audio Connectors (Four 4-pins) (optional)
VIDEO, MODEM
13) EARPHONE p.36 Headphone True-Level Line Out Header (3 pins)
14) MIC2 p.37 Internal Microphone Connector (3 pins)
15) AFPANEL/IR_CON p.37 ASUS iPanel Connector (12-1 pins)
16) AAPANEL p.37 ASUS iPanel Audio Connector (12-1 pins)
17) SMB p.38 SMBus Connector (5-1 pins)
