2-22 Chapter 2: Hardware information
Chapter 2
** Audio 2, 4, 6, or 8-channel conguration
Port
Headset
2-channel
4-channel 6-channel 8-channel
Light Blue Line In Line In Line In Line In
Lime Line Out Front Speaker Out Front Speaker Out Front Speaker Out
Pink Mic In Mic In Mic In Mic In
Orange –
– Center/Subwoofer
Center/Subwoofer
Black – Rear Speaker Out Rear Speaker Out Rear Speaker Out
Gray – – – Side Speaker Out
* LAN port LED indications
SPEED
LED
ACT/LINK
LED
LAN port
Activity Link LED Speed LED
Status Description Status Description
OFF
No link
OFF 10 Mbps connection
ORANGE Linked ORANGE 100 Mbps connection
BLINKING Data activity GREEN 1 Gbps connection
Dual display table
This table indicates whether the dual display you want to use is supported or not.
Dual display output Supported Not supported
DVI + D-Sub •
HDMI + D-Sub •
DVI + HDMI •
DVI + DisplayPort •
D-Sub + DisplayPort •
HDMI + DisplayPort •
