3-12 Chapter 3: BIOS setup
Chapter 3
Advanced Mode
The Advanced Mode provides advanced options for experienced end-users to congure
the BIOS settings. The gure below shows an example of the Advanced Mode. Refer to the
following sections for the detailed congurations.
To access the EZ Mode, click Exit, then select ASUS EZ Mode.
Menu bar
The menu bar on top of the screen has the following main items:
Main For changing the basic system conguration
Ai Tweaker For changing the overclocking settings
Advanced For changing the advanced system settings
Monitor For displaying the system temperature, power status, and changing the fan settings
Boot For changing the system boot conguration
Tool For conguring options for special functions
Exit For selecting the exit options and loading default settings
Main
Ai Tweaker
Advanced Monitor
Version 2.00.1201. Copyright (C) 2011 American Megatrends, Inc.
Back Advanced\ Onboard Devices Conguration >
EFI BIOS Utility - Advanced Mode
Menu bar
Submenu item
Conguration elds
Menu items
Pop-up window
Back button
HD Audio Device Enabled
Front Panel Type HD
SPDIF Out Type SPDIF
Realtek LAN Controller Enabled
Realtek PXE OPROM Disabled
Asmedia USB 3.0 Controller Enabled
Asmedia USB 3.0 Battery Charging Support Enabled
> Serial Port Conguration
Asmedia USB 3.0 Controller
Disabled
Enabled
