Asus F2A85-M User Guide

xii
Package contents
Check your motherboard package for the following items.
ASUS F2A85-M motherboard 2 x Serial ATA 6.0 Gb/s cables
User Manual
1 x I/O Shield User Guide Support DVD
• If any of the above items is damaged or missing, contact your retailer.
• The illustrated items above are for reference only. Actual product specications may
vary with different models.
F2A85-M
PCIEX16_1
PCIEX16_2
PCI1
PCIEX1_1
USB56USB78USB910
TPM
PANEL
SPDIF_OUT
AAFP
CPU_FAN
PWR_FAN
CHA_FAN
Lithium Cell
CMOS Power
Super
I/O
AUDIO
ALC
887-VD2
RTL
8111F
COM
KBMS_USB34
64Mb
BIOS
SB_PWR
CLRTC
AMD
®
A85X
DDR3 DIMM_A1 (64bit, 240-pin module) DDR3 DIMM_A2 (64bit, 240-pin module) DDR3 DIMM_B1 (64bit, 240-pin module) DDR3 DIMM_B2 (64bit, 240-pin module)
ESATA6G
_USB3
_12
LAN
_USB12
SATA6G_6 SATA6G_5
SATA6G_7
SATA6G_4 SATA6G_3
SATA6G_2 SATA6G_1
SPDIFO
_HDMI
MemOK!
DRAM_LED
DVI_VGA
SOCKET FM2
EATXPWR
USB3_34
GPU_LED
GPU Boost
ATX12V
DIGI+
VRM

Asus F2A85-M Specifications

General

Form Factor	Micro ATX
Chipset	AMD A85X (Hudson D4)
Socket	FM2
Max Memory	64GB
Memory Type	DDR3
SATA 6Gb/s	7 x SATA 6Gb/s
RAID Support	RAID 0, 1, 5, 10
Memory Standard	DDR3 2400(O.C.)/1866/1600/1333 MHz
PCI Express x1	2
USB 3.0 Ports	4 x USB 3.0 (2 at back panel, 2 via internal header)
USB 2.0 Ports	8 x USB 2.0 (4 rear, 4 via header)
Audio	Realtek 8-Channel High Definition Audio CODEC
LAN	Realtek RTL8111F Gigabit LAN Controller
Memory Slots	4 x DIMM
