Asus F2A85-M User Guide

ASUS F2A85-M
2-29
Conguration options: [OK]
Get KEK to File
Conguration options: [OK]
Delete the KEK
Conguration options: [Yes] [No]
Append an entry to KEK
Conguration options: [OK]
Set DB from File
Conguration options: [OK]
Get DB to File
Conguration options: [OK]
Delete the DB
Conguration options: [Yes] [No]
Append an entry to DB
Conguration options: [OK]
Set DBX from File
Conguration options: [OK]
Get DBX to File
Conguration options: [OK]
Delete the DBX
Conguration options: [Yes] [No]
Append an entry to DBX
Conguration options: [OK]
2.7.10 Setup Mode [EZ Mode]
[Advanced Mode] Sets Advanced Mode as the default screen for entering the BIOS setup
program.
[EZ Mode] Sets EZ Mode as the default screen for entering the BIOS setup program.
2.7.11 Boot Option Priorities
These items specify the boot device priority sequence from the available devices. The
number of device items that appears on the screen depends on the number of devices
installed in the system.
• To select the boot device during system startup, press <F8> when ASUS Logo
appears.
• To access Windows OS in Safe Mode, press <F8> after POST.
2.7.12 Boot Override
These items displays the available devices. The number of device items that appears on
the screen depends on the number of devices installed in the system. Click an item to start
booting from the selected device.

Asus F2A85-M Specifications

General

Form Factor	Micro ATX
Chipset	AMD A85X (Hudson D4)
Socket	FM2
Max Memory	64GB
Memory Type	DDR3
SATA 6Gb/s	7 x SATA 6Gb/s
RAID Support	RAID 0, 1, 5, 10
Memory Standard	DDR3 2400(O.C.)/1866/1600/1333 MHz
PCI Express x1	2
USB 3.0 Ports	4 x USB 3.0 (2 at back panel, 2 via internal header)
USB 2.0 Ports	8 x USB 2.0 (4 rear, 4 via header)
Audio	Realtek 8-Channel High Definition Audio CODEC
LAN	Realtek RTL8111F Gigabit LAN Controller
Memory Slots	4 x DIMM
