Asus M4A77T User Manual

DDR3-1333MHz capability
DDR3-1600(O.C.)MHz capability
We recommend that you install the DDR3 1600+ memory modules on the blue slots for
better overclocking performance.
(continued on the next page)
Vendor Part No. Size
SS/
DS
Chip
Brand
Chip NO. CL
DIMM support
A* B* C*
A-Data AD31600X002GMU 4096MB(Kit of 2) DS N/A Heat-Sink Package 7-7-7-20 •
Corsair CM3X1G1600C9DHX 2048MB(Kit of 2) SS N/A Heat-Sink Package 9-9-9-24 • • •
CRUCIAL BL12864BA1608.8SFB(XMP) 3072MB(Kit of 3) SS N/A Heat-Sink Package 8-8-8-24 • • •
CRUCIAL BL12864BE2009.8SFB3(EPP) 3072MB(Kit of 3) SS N/A Heat-Sink Package 9-9-9-28 • • •
Crucial BL25664TB1608.K16SF(XMP) 6144MB(Kit of 3) DS N/A Heat-Sink Package 8-8-8-24 •
Crucial BL25664TG1608.K16SF(XMP) 6144MB(Kit of 3) DS N/A Heat-Sink Package 8-8-8-24 • • •
Crucial BL25664TR1608.K16SF(XMP) 6144MB(Kit of 3) DS N/A Heat-Sink Package 8-8-8-24 • • •
G.SKILL F3-12800CL9D-2GBNQ 2048MB(Kit of 2) SS N/A Heat-Sink Package 9-9-9-24 • • •
G.SKILL F3-12800CL8T-6GBHK 2048MB DS N/A Heat-Sink Package 8-8-8-21 • • •
G.SKILL F3-12800CL9T-6GBNQ 6144MB(Kit of 3) DS N/A Heat-Sink Package 9-9-9-24 • • •
kingmax FLGD45F-B8KG9 1024MB SS kingmax KFB8FNGXF-ANX-12A N/A • • •
kingmax FLGE85F-B8KG9 2048MB DS kingmax KFB8FNGXF-ANX-12A N/A • • •
Kingston KHX12800D3LLK3/3GX(XMP) 3072MB(kit of 3) SS N/A Heat-Sink Package 8-8-8-24 • • •
Kingston KHX12800D3K2/4G 4096MB(kit of 2) DS N/A Heat-Sink Package 9-9-9-27 • • •
Kingston KHX12800D3LLK3/6GX(XMP) 6144MB(Kit of 3) DS N/A Heat-Sink Package 8-8-8-24 • • •
Vendor Part No. Size
SS/
DS
Chip Brand Chip NO. CL
DIMM support
A* B* C*
A-Data AD31333001GOU 1024MB SS A-Data AD30908C8D-151C E0906 N/A • •
A-Data AD31333002GOU 2048MB DS A-Data AD30908C8D-151C E0903 N/A • •
Apacer 78.01GC6.9L0 1024MB SS Apacer AM5D5808AEWSBG0914E 9 • • •
Apacer 78.A1GC6.9L1 2048MB DS Apacer AM5D5808AEWSBG0908D 9 • • •
Corsair CM3X1024-1333C9DHX 1024MB SS N/A Heat-Sink Package N/A • •
Corsair CM3X1024-1333C9 1024MB SS N/A Heat-Sink Package N/A • • •
CORSAIR TR3X3G1333C9
3072MB(Kit
of 3)
SS N/A Heat-Sink Package 9 • • •
Corsair CM3X1024-1333C9DHX 1024MB DS Corsair Heat-Sink Package N/A • • •
CRUCIAL BL12864TA1336.8SFB1
2048MB(Kit
of 2)
SS N/A Heat-Sink Package 6-6-6-20 • • •
Crucial MT8JTF12864AY-1G4D1
3072MB(Kit
of 3)
DS Micron 9FD22D9JNM 9 • • •
Crucial BL25664ABA1336.16SFB1
4096MB(Kit
of 2)
DS N/A Heat-Sink Package 6-6-6-20 • • •
Crucial MT16JTF25664AY-1G4D1
6144MB(Kit
of 3 )
DS Micron 8UD22D9JMN 9 • • •
G.SKILL F3-10600CL8D-2GBHK 1024MB SS G.SKILL Heat-Sink Package N/A • • •
G.SKILL F3-10600CL9D-2GBPK 1024MB SS G.SKILL Heat-Sink Package N/A • • •
G.SkiLL F3-10666CL7T-3GBPK
3072MB(Kit
of 3)
SS N/A Heat-Sink Package 7-7-7-18 • • •
G.SkiLL F3-10666CL9T-3GBNQ
3072MB(Kit
of 3)
SS N/A Heat-Sink Package 9-9-9-24 • • •
G.SKILL F3-10600CL7D-2GBPI 1024MB DS G.SKILL Heat-Sink Package N/A • • •
Chapter 1: Product introduction1-12

Asus M4A77T Specifications

General

ECC	Yes
Number of memory slots	4
Maximum internal memory	16 GB
Processor socket	Socket AM3
Processor manufacturer	AMD
Maximum number of SMP processors	1
Number of SATA connectors	6
Headphone outputs	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Motherboard chipset	AMD 770
Motherboard form factor	ATX
PCI Express x1 slots	2
Controller 2nd interface type	IDE/SATA
LAN controller	Realtek RTL8112L
ACPI version	2.0
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	213 mm
Width	305 mm
