ASUS M4A88TD-M/USB3 3-15
Chapter 3
3.5 Ai Tweaker menu
The Ai Tweaker menu items allow you to congure overclocking-related items.
Be cautious when changing the settings of the Ai Tweaker menu items. Incorrect eld
values can cause the system to malfunction.
The conguration options for this chapter vary depending on the CPU and DIMM model you
installed on the motherboard.
Scroll down to display the following items:
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
CPU Offset Voltage 1.350 [Auto]
CPU/NB Offset Voltage 1.100 [Auto]
CPU VDDA Voltage 2.500 [Auto]
DRAM Voltage 1.500 [Auto]
HT Voltage 1.200 [Auto]
NB Voltage 1.100 [Auto]
NB 1.8V Voltage 1.800 [Auto]
SB Voltage 1.100 [Auto]
***********************************************
CPU Load-Line Calibration [Auto]
CPU/NB Load-Line Calibration [Auto]
PCI/PCIe CLK Status [Enabled]
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
3.5.1 CPU Level UP [Auto]
Allows you to select a CPU level, and the related parameters will be automatically adjusted
according to the selected CPU level. If you want to manually congure the settings in detail,
set CPU Overclocking to [Manual] after selecting a CPU level.
Conguration options: [Auto] [Phenom II-955] [Phenom II-3.4G] [Phenom II-3.6G]
• The conguration options vary depending on the CPU model you install on the
motherboard.
• The CPU Level UP function support depends on CPU types.
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
M4A88TD-M/USB3 BIOS Setup
Main Ai Tweaker Advanced Power Boot Tools Exit
Warning: this function
belongs to overclock-
ing, and it may cause
instability.
Select a CPU level,
and the rest will be
auto-adjusted. If you
want to adjust more,
set Ai Overclock Tuner
to Manual after you
select a CPU level.
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Congure System Performance Settings
Target CPU Frequency : 3000MHz
Target DRAM Frequency: 1333MHz
CPU Level UP [Auto]
-------------------------------------------------
CPU Overclocking [Auto]
CPU Ratio [Auto]
DRAM Frequency [Auto]
CPU/NB Frequency [Auto]
HT Link Speed [Auto]
GPU Booster [Enabled]
Enhanced iGPU SpeedStep [Auto]
GPU Power Saving Mode [Disabled]
OC Tuner Utility
DRAM Timing Conguration
DRAM Driving Conguration
******* Please key in numbers directly! *******
CPU & NB Voltage Mode [Offset]
Version 0205
