Asus M6000 Series User Manual

DISASSEMBLY PROCEDURE
Battery Module
BATTERY
The illustration below shows how to remove the battery module.
1. Press latch to open the battery module, then lift battery module away from the system.
HDD Module
The illustrations below show how to remove the HDD module from the notebook.
Removing HDD Module
Remove 2 screws(M2*6L(K)), then remove the HDD cover and pull the hard disk module toward
the direction of the arrow and lift it up and take it out.
Second Memory Module
The M6000 Series Notebook do not have onboard RAM. There are two SO-DIMM
sockets for installing SO-DIMM RAM. It can upgrade the total memory size up to 2GB
with a 1GB module on each socket.
Removing Memory module
1. Remove 2 screws(M2*3L(K) ) , then take the memory DIMM cover away.
HDD MODULE
HDD MODULE
REMOVAL
SECOND
MEMORY
MODULE
MEMORY
REMOVAL
M2*6L
3 - 2
