Asus M6000 Series User Manual

DISASSEMBLY PROCEDURE
First Memory Module
FIRST
MEMORY
MODULE
REMOVAL
The first memory module is under keyboard. Open the two latches to pop up memory module at
45 degrees angle then pull it out .
Mini PCI Module
WIRELESS
LAN MODULE
This slot usually has Wireless LAN module when leaving the factory, this slot is for
optional system upgrade.
Removing Wireless LAN Module
WIRELESS
LAN
REMOVAL
1. Remove 1 screw(M2*3L(K)), then take the mini-PCI cover off.
M2*3L
2. Disconnect 2 antenna cables, then open two latches to pop up wireless LAN module at 45
degrees angle and pull it out.
3 - 6
