8 Installation manual
English
NOTE: For P2 model, if your optical
drive tray fails to eject when you press
the eject button, attach the provided
sticker to the location shown at the back
of the front panel cover. Make sure the
sticker aligns with the optical drive eject
button.
1. Insert the foot stand hooks into
the holes on the chassis.
Installing the foot stand
2. Pull the foot stand to the direction
of the arrow until the lock snaps
in place.
NOTE: To remove the foot stand, lift the lock, then slightly push the foot stand to the
direction of the rear panel until it disengages from the chassis.
Reinstalling the cover
1. Insertthecovertothechasis.Makesurethecovertabstthechasisrails.
2. Pushthecovertowardthefrontpaneluntilittsinplace.
3. Secure the cover with two screws you removed earlier.
Reinstalling the front panel cover
NOTE: Refer to the pictures in the section “Removing the cover” on page 3 in reverse
order.
R
2
1. Insert the front panel
cover tabs to the holes
on the right side of the
chassis, then swing
the front panel cover to
the left.
2. Insert the front panel
cover hooks to the
chassis until the front
panelcovertsin
place.
Sticker
1
