Asus P535 User Manual

122
The ASUS status icon allows you to easily check and see the current status of the following
device components: CPU, USB, LCD Brightness, Battery power, Memory, MiniSD card, and
storage.
To check the status of these components, tap the ASUS Status icon on the Today screen.
ASUS status icon
CPU: Allows you to set the CPU mode. Set to
Automatic Mode to automatically change the CPU
speed according to the CPU loading.
USB: Allows you to set the USB connection mode.
Brightness: Tap to adjust the LCD brightness on
battery power or external power.
Power: Displays the remaining battery power and
allows you to set advanced power saving features.
Memory: Displays the total, currently used, and
remaining memory available.
Storage card memory: Displays the total, used,
and remaining storage card memory.
MiniSD card: Tap to display the contents of the
miniSD card installed.
Settings: Allows you to select the items to display in
this ASUS Status pop-up menu.

Asus P535 Specifications

General

Processor	Intel XScale® processor, 520MHz
Operating System	Microsoft® Windows Mobile™ 5.0 Pocket PC Phone Edition
Memory	256 MB NAND Flash ROM 64 MB SDRAM
Expansion slot	MiniSD card slot
Display	2.8-inch, 65, 536-color, 240 x 320-resolution, TFT touch screen LCD
Frequency band	Tri-band GSM (900/1800/1900 MHz)
GPRS	Class B, Multislot class 10
Connectivity	WLAN : 802.11b/g Bluetooth : V2.0 + EDR USB : USB Client 1.1
GPS	Built-in SiRF III GPS chipset
Camera	2.0 mega-pixel CMOS camera with Auto-Focus (AF) and built-in flash
Battery capacity	1300 mAh Lithium Ion
Talk time*	4~5 hrs (*vary with different networking environment and scenario)
Standby time*	150~200 hrs (*vary with different networking environment and scenario)
Audio	2.5 mm audio port Built-in microphone and speaker

Weight and Dimensions

Weight	145g (with battery)
Dimension	109 x 59 x 19 mm
