Asus P535 User Manual

31
Using the Transcriber
Transcriber is a handwriting recognition program that allows you to write in cursive, print, or
mixed styles. It reliably recognizes not only written text but also numbers and symbols. Make
sure to write legibly. See Help for more information on the Transcriber.
To use the Transcriber:
1. Start an application that accepts user input, such as Notes or Word Mobile.
2. Tap the Input Panel arrow, then tap Transcriber.
To write using Transcriber (using Notes):
1. Tap screen to position the cursor where you want the text to appear.
2. Use the stylus to write on the screen. The handwriting will be converted to text after you
lift the stylus from the screen.
To edit text:
1. Draw a line across the text you want to edit. After you lift the stylus from the screen, the
line will disappear and the selected text will be highlighted.
2. You can now rewrite the text or use the Transcriber gestures to edit your selected text.
See Help for the Transcriber gestures.
Input panel
Tap for Help

Asus P535 Specifications

General

Processor	Intel XScale® processor, 520MHz
Operating System	Microsoft® Windows Mobile™ 5.0 Pocket PC Phone Edition
Memory	256 MB NAND Flash ROM 64 MB SDRAM
Expansion slot	MiniSD card slot
Display	2.8-inch, 65, 536-color, 240 x 320-resolution, TFT touch screen LCD
Frequency band	Tri-band GSM (900/1800/1900 MHz)
GPRS	Class B, Multislot class 10
Connectivity	WLAN : 802.11b/g Bluetooth : V2.0 + EDR USB : USB Client 1.1
GPS	Built-in SiRF III GPS chipset
Camera	2.0 mega-pixel CMOS camera with Auto-Focus (AF) and built-in flash
Battery capacity	1300 mAh Lithium Ion
Talk time*	4~5 hrs (*vary with different networking environment and scenario)
Standby time*	150~200 hrs (*vary with different networking environment and scenario)
Audio	2.5 mm audio port Built-in microphone and speaker

Weight and Dimensions

Weight	145g (with battery)
Dimension	109 x 59 x 19 mm
