Asus P535 User Manual

85
Navigation button functions in camera mode
The following describes the navigation button functions in Camera mode:
ENTER/ACTION Button
Forward
Up
Down
Backward
Up
In camera preview mode, press for video mode.
In the camera or video option menu, press to select menu items.
Down
In video preview mode, press for camera mode.
In the video or camera options menu, press to select menu items.
Backward
In camera mode and if the resolution is not 1600x1200, press to
zoom in.
Forward
In camera mode and if the resolution is not 1600x1200, press to
zoom out.
Enter/Action button
Press to take picture or start/stop recording video.
Press to execute a selected menu item or to display more menu
items.

Asus P535 Specifications

General

Processor	Intel XScale® processor, 520MHz
Operating System	Microsoft® Windows Mobile™ 5.0 Pocket PC Phone Edition
Memory	256 MB NAND Flash ROM 64 MB SDRAM
Expansion slot	MiniSD card slot
Display	2.8-inch, 65, 536-color, 240 x 320-resolution, TFT touch screen LCD
Frequency band	Tri-band GSM (900/1800/1900 MHz)
GPRS	Class B, Multislot class 10
Connectivity	WLAN : 802.11b/g Bluetooth : V2.0 + EDR USB : USB Client 1.1
GPS	Built-in SiRF III GPS chipset
Camera	2.0 mega-pixel CMOS camera with Auto-Focus (AF) and built-in flash
Battery capacity	1300 mAh Lithium Ion
Talk time*	4~5 hrs (*vary with different networking environment and scenario)
Standby time*	150~200 hrs (*vary with different networking environment and scenario)
Audio	2.5 mm audio port Built-in microphone and speaker

Weight and Dimensions

Weight	145g (with battery)
Dimension	109 x 59 x 19 mm
