2.2.5 Layout contents
Slots Page
1. DDR2 DIMM slots 2-15
2. PCI slots 2-20
3. PCI Express x1 slot 2-20
4. PCI Express x16 slots 2-20
Jumper Page
1. Clear RTC RAM (3-pin CLRTC_EN) 2-21
Rear panel connectors Page
1. PS/2 mouse port (green) 2-23
2. Coaxial S/PDIF Out port 2-23
3. LAN 1 (RJ-45) port. 2-23
4. LAN 2 (RJ-45) port 2-23
5. USB 2.0 ports 1 and 2, 3 and 4 2-25
6 IEEE1394a port 2-25
7. Optical S/PDIF Out port 2-25
8. PS/2 keyboard port (purple) 2-25
Supreme FX Page
1. Line In port (light blue) 2-24
2. Line Out port (lime) 2-24
3. Microphone port (pink) 2-24
4. Center/Subwoofer port (orange) 2-24
5. Side Speaker Out port (gray) 2-24
6. Rear Speaker Out port (black) 2-24
