ASUS P6X58-E PRO 3-23
Chapter 3
3.6.2 Chipset
The Chipset menu allows you to change the advanced chipset settings. Select an item and
press <Enter> to display the submenu.
North Bridge Chipset Conguration
BIOS SETUP UTILITY
Advanced
North Bridge Chipset Conguration
Revision :B3
PCI Express Selector [Auto]
Select PCIE Slot#2
and PCIE Slot#3 Link
Width x8 + x8 or
x16 + x1
BIOS SETUP UTILITY
Advanced
Advanced Chipset Settings
WARMING: Setting wrong values in below sections
may cause system to malfunction.
North Bridge Conguration
Intel VT-d Conguration
Congure North Bridge
features.
PCI Express Selector [Auto]
Allows you to decide the Link Width of the PCIe x16_2 slot and PCIe x16_3 slot.
Conguration options: [Auto] [x8 x8 Mode] [x16 x1 Mode]
