6
Rear view
SATA power
connector
Connects to a SATA power cable from the Power
supply for additional power source.
ROG_EXT
connector
Connects with the motherboard’s ROG_EXT
connector.
AAFP connector Connects with the motherboard’s Front panel audio
connector (AAFP) for high-denition audio support.
IMPORTANT! Allot two (2) empty 5.25-inch drive bays for ROG Front Base
installation.
