Asus ROG G20AJ User Manual

Audio 2.1, 4.1, 5.1, or 7.1-channel configuration
Port Headset 2.1-channel 4.1-channel 5.1-channel 7.1-channel
Light Blue (Rear panel) Line In Rear Speaker Out Rear Speaker Out Rear Speaker Out
Lime (Rear panel) Line Out Front Speaker Out Front Speaker Out Front Speaker Out
Pink (Rear panel) Mic In Mic In Bass/Center Bass/Center
Front panel - - - Side Speaker Out
LAN (RJ-45) port. This port allows Gigabit connection to a Local Area Network (LAN)
through a network hub.
Activity/Link LED Speed LED
Status Description Status Description
OFF No link OFF 10Mbps connection
ORANGE Linked ORANGE 100Mbps connection
BLINKING Data activity GREEN 1Gbps connection
LAN port
SPEED
LED
ACT/LINK
LED
Side Speaker Out port (gray). This port connects to the side speakers in an 8-channel
audio configuration.
Rear Speaker Out port (black). This port connects to the rear speakers in a 4, 6, and
8-channel audio configuration.
Center/Subwoofer port (orange). This port connects to the center/subwoofer
speakers.
Microphone port (pink). This port connects to a microphone.
Line Out port (lime). This port connects to a headphone or speaker. In a 4.1, 5.1,
or 7.1-channel configuration, the function of this port becomes Front Speaker Out.
Supported by ASUS Audio Wizard.
Line In port (light blue). This port connects to a tape, CD, DVD player, or other audio
sources.
Refer to the audio configuration table below for the function of the audio ports in a 2.1, 4.1,
5.1, or 7.1-channel configuration.
16 Chapter 1: Getting started
ENGLISH
ENGLISH

Asus ROG G20AJ Specifications

General

Tcase	72.72 °C
Bus type	DMI
Stepping	C0
Processor cache	6 MB
Processor cores	4
Processor model	i5-4460
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-4400 Desktop series
Processor socket	LGA 1150 (Socket H3)
Processor codename	Haswell
Number of QPI links	0
Processor frequency	3.2 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.4 GHz
Processor operating modes	32-bit, 64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	84 W
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
Memory slots	2x SO-DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	-
Total storage capacity	1000 GB
Number of HDDs installed	1
On-board graphics card	Yes
On-board graphics card ID	0x412
Discrete graphics card model	NVIDIA® GeForce® GTX 760
On-board graphics card model	Intel® HD Graphics 4600
Discrete graphics card memory	2 GB
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.024 GB
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	11.1
On-board graphics card dynamic frequency (max)	1100 MHz
Number of displays supported (on-board graphics)	3
Operating system installed	Windows 8.1
Operating system architecture	64-bit
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Black, Red
Product type	PC
Motherboard chipset	Intel® H97
Audio output channels	7.1 channels
Scalability	1S
Processor code	SR1QK
Processor ARK ID	80817
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX 2.0
Thermal solution specification	PCG 2013D
Intel Identity Protection Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00

Weight and Dimensions

Depth	358 mm
Width	104 mm
Height	340 mm
Weight	6380 g
Package depth	592 mm
Package width	190 mm
Package height	400 mm
